3.6
SDMMC Interface (CN20)
Table 3-5 lists the pin signals of the SD Card ground plane socket, which provides 60-pins, 2
rows, odd/even pin sequence (1, 2) with 0.50mm pitch. These signals are connected to the SD/
eMMC interface at pins S26 through S36 of the SMARC connector over a 3.3 volt level shifter.
Pin #
1
GND
2
GND
3
MMC_D0
4
GND
5
GND
6
GND
7
GND
8
GND
9
MMC_D1
10
GND
11
GND
12
GND
13
GND
14
GND
15
MMC_D2
16
GND
17
GND
18
GND
19
GND
20
GND
21
MMC_D3
22
VDD_3V3
23
GND
24
GND
25
GND
26
GND
27
MMC_D4
28
VDD_3V3
29
GND
30
GND
31
GND
32
GND
33
MMC_D5
34
GND
35
GND
36
GND
37
GND
38
GND
39
MMC_D6
40
GND
22
Table 3-5: SD/eMMC Interface Signals (CN20)
Signal
Ground
Ground
MMC data bit0
Ground
Ground
Ground
Ground
Ground
MMC data bit1
Ground
Ground
Ground
Ground
Ground
MMC data bit2
Ground
Ground
Ground
Ground
Ground
MMC data bit3
3.3 Volt power supply
Ground
Ground
Ground
Ground
MMC data bit4
Ground
Ground
Ground
Ground
MMC data bit5
Ground
Ground
Ground
Ground
Ground
MMC data bit6
Ground
Description
