2.2.2

PCIe Mini Card Slot

The LEC-BASE MINI provides two standard PCI Express Mini Card slots. Figure 2-6 presents
one mini card slot with one of the two fastening latches. Figure 2-7 illustrates the functional
block diagram of the PCIe Mini Card signals and hardware on the carrier.
M XM
Connector
M XM
Connector
14
Figure 2-6: PCIe Mini Card Slot with Latch
PCIe x1
SIM slot
(CN 8)
USB
USB H ub
PCIe x1
SIM slot
(CN 10)
USB
USB H ub
Figure 2-7: PCIe Mini Card Slot Block Diagram
M ini
PCIe
SIM
Slot 1
(CN 7)
USB2.0
M ini
PCIe
SIM
Slot 2
(CN 9)
USB2.0
Hardware
