Hardware Installation and Reference Guide
1.4.2

Radio Specifications

Table 1-4 Radio Specifications
Item
Radio Design
Operating Frequencies
Data Rate
Antenna Type
Antenna Gain
Max. Transmit Power
Power Adjustment
Modulation
RG-AP180P-L
Dual-radio
Up to four spatial streams
Radio 1: 2.4 GHz, two spatial streams: 2 × 2, MIMO
Radio 2: 5 GHz, two spatial streams: 2 × 2, MIMO
Radio 1: 802.11b/g/n/ax, 2.400 GHz to 2.483 GHz
Radio 2: 802.11a/n/ac/ax, 5.150 GHz to 5.350 GHz, 5.470 GHz to 5.725 GHz,
5.725 GHz to 5.850 GHz
Note: The operating frequencies vary in different countries.
Radio 1: 2.4 GHz, 575 Mbps
Radio 2: 5 GHz, 2.4 Gbps
Combined data rate:
2.4 GHz+5 GHz, 2.975 Gbps
Built-in smart antenna
2.4 GHz: 3 dBi
5 GHz: 3 dBi
20 dBm
Note: The transmit power varies based on the regulations in different countries
and regions.
Configurable in increments of 1 dBm
OFDM: BPSK (6 and 9 Mbps), QPSK (12 and 18 Mbps), 16-QAM (24 Mbps),
64-QAM (48 and 54 Mbps)
DSSS: DBPSK (1 Mbps), DQPSK (2Mbps), and CCK (5.5 and 11 Mbps)
MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, and 1024QAM
OFDMA
6
Product Introduction
