The test conditions can also be determined automatically by the AT3600 according to
this table:
Note that a 'fixed' voltage signal cannot be used with an 'Auto' frequency.
T T C
ESTS AND EST ONDITIONS
M
ANUAL
Inductance of the
Energised Winding
→
100nH
→
1uH
→
10uH
→
100uH
→
1mH
→
10mH
→
100mH
→
1H
→
10H
→
100H
→
1kH
Voltage
Frequency
Preferred test signal
Frequency
1µH 300kHz
10µH 100kHz
100µH 30kHz
1mH 10kHz
10mH 1kHz
100mH 100Hz
1H 100Hz
10H 50Hz
100H 50Hz
1kH 50Hz
10kH 20Hz
Specified Auto
Specified Specified
