Versatile – Many different types of test are all performed automatically. The range of
tests available is being constantly expanded, but common test types include:
I
NTRODUCTION
ANUAL
PERATION
Manual or robotic operation
Barcode input
Footswitch input
Simple PASS / FAIL operation by an unskilled operator
Safe – Light barrier controlled power isolation prevents operator injury from
high voltages. (Chapters 8 & 10.)
ESULTS
Direct printing from the AT Series Tester.
Results archiving to disk using the Server application.
Results for analysis can be easily exported to other Windows applications.
EASUREMENTS
Continuity
DC Resistance
Primary Inductance (Series or Parallel)
Q Factor
Equivalent Resistance (Series or Parallel)
Leakage Inductance
Capacitance
Turns Ratio and Phasing
Inductance with Bias Current (Series or Parallel)
Insulation Resistance
Magnetizing Current
Open Circuit Voltage
Hi-Pot (DC)
Hi-Pot (AC)
Surge Stress Test
Hi-Pot Ramp (AC)
Hi-Pot Ramp (DC)
VPN 98 - 024
AT3600 F
S
EATURES
UMMARY
P
1.2.3.
AGE
