5. Set the voltage limits.
6. Polarity testing can be included in the test by selecting either positive or negative
7. Select OK. The test specification will be displayed in the program window on the
P 3.4.58.
AGE
Click on the arrow to the right of the fill-in box, and you will be provided with a
choice of available terminals; double-click on the one required.
Similarly, enter the names for the Measured Terminals.
% Enter a nominal value and then the limits as negative and positive
percentage values.
>< Enter minimum and maximum values.
> Enter just a minimum value.
< Enter just a maximum value.
Note that the Measure button may be used here as outlined in section
3.9.
radio buttons to test against. Here the polarity test will produce either Pass or Fail
results. Polarity testing is not possible if the source type is 'Manual Source / Line
Supply'. (For ac measurements, use the positive polarity when the measured
winding has the same phase as the energized winding, use the negative polarity
when they have opposite phases.)
screen.
