Voltech AT3600 User Manual page 194

T R H
EST ESULTS ANDLING
Select 'Display Basic Statistics' to save results to a database. For this feature to
operate a licence for use must first be obtained from your Voltech supplier.
All results formats can be saved simultaneously.
Basic statistics displays, on-line, a summary of the results for the current batch of
transformers that is being tested on every AT connected to the Server. Results for
previous batches can also be opened and the statistics displayed and printed.
The batch statistics window display is automatically shown once this feature is
enabled. For each AT connected to the Server the following information is displayed:
The type of AT and its serial number, and the part name, operator and batch.
PASS or FAIL for the last part tested, the total tested so far and the serial number of
the last part tested.
The number that have passed and failed, and the AQL<+> (Acceptable Quality
Level) of the transformer.
The number of re-tries that have been attempted, the percentage of failures so far and
the number of transformers that failed out of the last 10 tested.
For each test in the program, the test limits, the last result and the accumulated
number of fails for each test.
