P T
ROGRAMMING ESTS
To program the test:
1. Enter the value of a voltage (or current) for the signal and the required frequency
of the test.
Also enter the bias current you would like to apply.
Please note that the Measure button may be used here. For information, refer to
the 'Test Program Editor' of your AT manual.
2. Select the integration time required. 'Medium' is the default setting. 'Long' will
give more stable readings (for tighter limits) at the expense of time, and 'Short'
will test at the maximum speed, but may give slightly noisier readings.
3. Enter the terminal names between which the impedance is to be measured.
4. Set the impedance limits.
+/- Enter a nominal value and then the limits as negative and positive values.
><
>
5. Select OK. The test specification will then be displayed in the program window.
P 3.4.68.
AGE
Enter minimum and maximum values.
Enter just a minimum value.
< Enter just a maximum value.
