3. Select (mouse click the button) the integration time you require.
4. Enter the terminal names for the Energized High and Low Terminals.
5. Similarly, enter the names for the Measured Terminals.
6. Select (mouse click the button) the type of limits you require and enter the
7. Click on the appropriate button to choose the polarity, or choose the 'No Test'
P 3.4.56.
AGE
'Medium' is the default setting. 'Long' will give more stable readings (for tighter
limits) at the expense of an increased test time, and 'Short' will test at the
maximum speed, but may give a slightly noisier reading.
Click on the arrow to the right of the fill-in box, and you will be provided with a
choice of available terminals; double-click on the one required.
values.
% Enter a nominal value and then the limits as negative and positive
percentage values.
>< Enter minimum and maximum values.
> Enter just a minimum value.
< Enter just a maximum value.
Note that the Measure button may be used here as outlined in section 3.9.
button. (For ac measurements, use the positive polarity when the measured
winding has the same phase as the energized winding, use the negative polarity
when they have opposite phases.)
Select OK. The test specification will then be displayed in the program window.
