This section describes in more detail how to fill in the data for the dialogue boxes for
each of the tests available for your AT3600.
By the end of this chapter you will be able to program any of the following tests :
SEE ALSO:
Chapter 7 - 'Test Conditions' for help with selecting the tests and test signal
conditions that you need.
AND:
The tester's measure mode can also be used to determine the nominal values of a new
part. See section 3.9 of this chapter.
T P E
EST ROGRAM DITOR
M
ANUAL
ROGRAMMING
Test Type
Continuity
Resistance (dc)
Resistance (ac), series or parallel
Inductance, series or parallel
Inductance with Internal Bias
Quality Factor
Dissipation factor
Leakage Inductance
Inter-winding Capacitance
Turns Ratio
Turns Ratio By Inductance
Impedance
Impedance with Internal Bias
Inductance Match
Capacitance Match
General Longitudinal Balance
Longitudinal Balance
Insertion Loss
Frequency Response
Return Loss
Impedance Phase Angle
Inter Winding Phase Angle
T
ESTS
Wattage (External Source)
Stress Watts (External Source)
Mag. Current (External Source)
Voltage O/C (External Source)
Low Voltage Open Circuit
Inductance with External Bias
Impedance with External Bias
Voltage Break Down (AC)
Voltage Break Down (DC)
VPN 98 - 024
P
ROGRAMMING
Test Type
Trimming Adjustment
Output To User Port
Insulation Resistance
Hi-Pot (DC)
Hi-Pot (AC)
Surge (Impulse)
Wattage
Stress Wattage
Magnetizing Current
Voltage Open Circuit
Leakage Current
Hi-Pot Ramp (AC)
Hi-Pot Ramp (DC)
T
ESTS
