Choosing the test limits
The test limits can be:
Use the PC Editor's 'measure' button (together with a sample part) if you are unsure
of the nominal value.
Typically, D is tested against a maximum value. A typical film dielectric capacitor
may have a D < 0.01. Because D is a ratio of two impedances it has no units.
T P E
EST ROGRAM DITOR
M
ANUAL
% A nominal value together with + and – percentage limits.
>< Minimum and maximum values
> A minimum value only
< A maximum value only
