I
NTRODUCTION
Also available for the AT3600, the Voltech 'AC Source Interface' extends the
possible test range of the AT3600 test signal generators up 600V, 10A when used
with a suitable external supply.
Over 35 different tests are available for the AT3600. Check our website at
i
www.voltech.com for details of new tests. Most can be installed within a few
minutes by purchasing a software upgrade.
To determine which options were installed on your tester during manufacture, check
the list attached to the calibration certificate inserted in the pocket on the inside
front cover of this manual.
P 1.1.4.
AGE
Features:
20 way switching matrix
PC test editor and results server
Test fixture system
Small signal tests ( e.g. inductance, capacitance, turns !
Telecomms. tests (e.g. return loss, longitudinal !
Insulation resistance
Hi-pot (AC)
Hi-pot (DC)
Surge testing
Magnetizing current and open circuit voltage
Watts, Stress Watts
Leakage Current
Hi-pot Ramp (AC)
Hi-pot Ramp (DC)
VPN 98 - 024
V AT3600 U M
OLTECH SER
ATi AT3600
! !
! !
! !
!
!
500V 7000V
5500V
7000V
5000V
270V
!
!
5500V
7000V
