Installation, connection and commissioning

3 Installation, connection and commissioning
3.1

Dimensions

3.2

Installation

CAUTION
When operating on system voltages U
• Mount AGH with 30 mm lateral clearance to adjacent devices.
3.3

Connection

CAUTION
If the AGH is operated at mains voltages > 800 V, the temperature of the enclosure may exceed 60 °C.
• Do not touch the surfaces of the device after connecting it to the mains voltage.
18 isoCHA425HV_D00404_04_M_XXEN/10.2023
36
Figure: Dimension diagram (in mm)
Property damage due to heat
Figure: DIN rail mounting (left) or screw mounting (right)
Danger from touching hot surfaces!
93 90
31.1
47.5
74.5
> 800 V, the housing of the AGH can become hotter than 60 °C.
n
45 70.5
