Bender ISOMETER isoCHA425HV Manual page 50

Technical data
6.5 Ordering data
ISOMETER®
Type
isoCHA425HV-D4-4 + AGH420-1
isoCHA425HV-D4-4 + AGH421-1
Accessories
Mounting clip for screw mounting
XM420 mounting frame
6.6 Document revision history
Date Document
version
11/2021 02
02/2023 03
50 isoCHA425HV_D00404_04_M_XXEN/10.2023
Nominal voltage U
CCS: DC 0...1000 V
CHAdeMO: DC 50...1000 V
CCS: DC 0...1000 V
CHAdeMO: DC 50...1000 V
Description
Valid from
software
D624 V1.00 Added:
Data about Mode CHA in chapter
Device features
RF and Ce in Mode „CHd" and „CHA" (CHAdeMO)
Menu „SEt"
Modbus register assignment of the ISOMETER® (at register 3032)
Info about screw terminal in Technical Data (at AGH420-1)
Ordering information
Changes:
Chapter Menu „AL" Description LED on / off
D624 V4.02 Editorial revision
3.1 Dimension drawing new
3.3 Connection diagram new
3.4 Setting insulation monitoring mode incl. note
4.1 Note „Readability ..."
4.5.1 Note „To comply with UL2231 ..."
9.0 TD: ModeCCS (dc), climatic classes
9.1 Climate classes; UL2231
9.3 EU conformity
9.4 Modification history
n
Set
B71036396
B71036399
B98060008
B990994
State/Changes
Article number
Contents
B71036394
B78039033
B71036394
B78039034
Article number
