Operation
4.5.3

Activating or deactivating fault memory

Display
M
FAC Factory settings
Cs Customer settings
4.5.4

Configuring interface

Display
Adr 0 / 3...90
Adr 1
1.2k...115k
Adr 2
FAC Factory settings
Cs Customer settings
( ) Customer setting that is not modified by FAC.
Adr 2 can only be selected, if Adr 1 is not "---".
4.6

Setting delay times and self test cycles (t)

Open menu "t" to configure the times.
Display
t
ton
toff
test OFF/1/24
FAC Factory settings
Cs Customer settings
To comply with the standard UL 2231, the parameter "test" must be "OFF".
28 isoCHA425HV_D00404_04_M_XXEN/10.2023
FAC Cs
off
Setting value
Range FAC
3
---
19,2k
8E1
8o1
8E1
8n1
8n2
Setting value
Range FAC
0...10 0
0...99 0
0...99 0
OFF
Memory function for alarm messages (fault memory)
Cs
( ) Bus Adr.
( ) Baud rate
( ) Modbus
Cs
s Start-up delay when starting the device
s Response delay K1 and K2
s Delay on release K1 and K2
h Repetition time for device test
Description
Description
Adr = 0 deactivates BMS as well as Modbus
and activates isoData with continuous data
output (115k2, 8E1)
"---": BMS bus (9k6, 7E1)
"1.2k" ... "115k": Modbus (variable)
8E1 - 8 data bits, even parity, 1 stop bit
8o1 - 8 data bits, odd parity, 1 stop bit
8n1 - 8 data bits, no parity, 1 stop bit
8n2 - 8 data bits, no parity, 2 stop bits
Description
