Bender ISOMETER isoCHA425HV Manual page 45

Time response
Start-up delay t
Response delay t
on
Delay on release t
off
Interface
Interface / protocol
Baud rate
Cable length (9.6 kBits/s)
Cable: twisted pairs
Terminating resistor
Device address, BMS bus, Modbus RTU
Switching elements
Switching elements
Operating principle
Electrical endurance under rated operating conditions
Contact data acc. to IEC 60947-5-1
Utilisation category
Rated operational voltage
Rated operational current
Minimum contact load
Contact data acc. to UL 508
Rated operational voltage
Rated operational current
RS-485 / BMS, Modbus RTU, isoData
BMS (9.6 kBit/s), Modbus RTU (selectable),
120 (0.25 W), internal, can be connected
2 × 1 n/o contact, common terminal 11
n/cC operation, n/o operation (n/c operation)*
AC-12 / AC-14 / DC-12 / DC-12 / DC-12
isoCHA425HV_D00404_04_M_XXEN/10.2023
ISOMETER® isoCHA425HV
0...10 s (0 s)*
0...99 s (0 s)*
0...99 s (0 s)*
isoData (115.2 kBits/s)
min. J-Y(St)Y 2 × 0.6
10,000 cycles
230 V / 230 V / 24 V / 110 V / 220 V
5 A / 2 A / 1 A / 0.2 A / 0.1 A
1 mA at DC ≥ 5 V
≤ 1200 m
3...90 (3)*
AC 250 V
2 A
