IsoData data string

In IsoData mode the ISOMETER® sends the entire data string roughly once per second. Communication with
the ISOMETER® in this mode is not possible and no additional sender may be connected via the RS-485 bus
cable.
IsoData is activated in the menu "out", menu item "Adr", when Adr is set to 0. In this case, the "Adr" symbol
flashes on the measured value display.
String
!; Start symbol
v; Insulation fault location " " / "+" / "–"
123456; Insulation resistance R
12345; System leakage capacitance C
123456; Reserved
+1234;
+1234; Residual DC voltage U
+1234; Residual DC voltage U
+123; Insulation fault location –100 ... +100 [%]
123456; Insulation resistance R
1234;
12;
<CR><LF> String end
F
System voltage U [V
n trueRMS
System voltage type: AC or unknown: " " | DC: "+" / "–"
L1e
L2e
FU
Alarm message [hexadecimal] (without leading "0x")
The alarms are included in this value with the OR function.
Assignment of the alarms:
0x0002 device error
0x0004 Prewarning insulation resistance R
0x0008 Prewarning insulation resistance R
0x000C Prewarning insulation resistance R
0x0010 Alarm insulation resistance R
0x0020 Alarm insulation resistance R
0x0030 Alarm insulation resistance R
0x0040 Alarm message undervoltage U
0x0080 Alarm message overvoltage U
0x0100 Manually started self test
0x0200 Device start with alarm
Update counter, consecutively counts from 0 to 99.
It increases with the update of the insulation resistance value.
Description
[k ]
[nF]
e
]
[V]
[V]
[k ]
at L1/+
F
at L2/–
F
symmetrical
F
at L1/+
F
at L2/–
F
symmetrical
F
n
n
