Technical data
Classification of climatic conditions acc. to IEC 60721 (related to temperature and relative humidity)
Stationary use (IEC 60721-3-3)
Transport (IEC 60721-3-2)
Long-term storage (IEC 60721-3-1)
Classification of mechanical conditions acc. to IEC 60721
Stationary use (IEC 60721-3-3)
Transport (IEC 60721-3-2)
Long-term storage (IEC 60721-3-1)
Other
Operating mode
Mounting
Distance to adjacent devices from U
Degree of protection internal components (DIN EN 60529)
Degree of protection terminals (DIN EN 60529)
Enclosure material
DIN rail mounting acc. to
Screw mounting
Weight
6.3 Connection (for ISOMETER® and AGH) (for ISOMETER® and ZE420)
Push-wire terminals
Nominal current
Conductor sizes
Stripping length
Rigid
Flexible without ferrules
Flexible with ferrules with/without plastic sleeve
Multi-conductor flexible with TWIN ferrules with plastic sleeve
Opening force
Test opening
48 isoCHA425HV_D00404_04_M_XXEN/10.2023
> 800 V
n
continuous operation
cooling slots must be ventilated vertically
2 x M4 with mounting clip
3K22
2K11
1K22
3M11
2M4
1M12
≥ 30 mm
IP30
IP20
polycarbonate
IEC 60715
≤ 150 g
≤ 10 A
AWG 24...14
10 mm
0.2...2.5 mm 2
0.75...2.5 mm 2
0.25...2.5 mm 2
0.5...1.5 mm 2
50 N
Ø 2.1 mm
