Bender ISOMETER isoCHA425HV Manual page 38

Data access via RS-485 interface
Register Property
3010 RW
3011 RW
3012 RW
3013 RW
3014 RW
3015 RW
3016 RW
3017 RW
3018 RW
3019 RW
3020 RW
3021 RW
3022 RW
3023 RW
3024 RW
3025 RW
38 isoCHA425HV_D00404_04_M_XXEN/10.2023
Description
Activation alarm value overvoltage "U>"
Alarm value overvoltage "U>"
Memory function for alarm
messages (fault memory) "M"
Operating mode of relay K1 "r1"
Operating mode of relay K2 "r2"
Bus address "Adr"
Baud rate "Adr 1"
Parity "Adr 2"
Start-up delay "t" during device start
Response delay "ton" for relays "K1" and "K2"
Delay on release "toff" for relays "K1" and "K2"
Repetition time "test"
for automatic device test
Reserved
Insulation monitoring mode
Test of the system connection
during device test "nEt"
Device test during device start "S.Ct"
Format Unit
UINT 16
UINT 16 V
UINT 16
UINT 16
UINT 16
UINT 16
UINT 16
UINT 16
UINT 16 s
UINT 16 s
UINT 16 s
UINT 16
UINT 16
UINT 16
UINT 16
Value range
0 = off
1 = on
U< ... 1100
0 = off
1 = on
0 = n/o
1 = n/c
0 = n/o
1 = n/c
0 / 3...90
0 = BMS
1 = 1.2 k
2 = 2.4 k
3 = 4.8 k
4 = 9.6 k
5 = 19.2 k
6 = 38.4 k
7 = 57.6 k
8 = 115.2 k
0 = 8N1
1 = 8O1
2 = 8E1
3 = 8N2
0 ...10
0 ... 99
0 ... 99
0 = off
1 = 1 h
2 = 24 h
0 = dc
1 = CHd
2 = CHA
0 = off
1 = on
2 = on U
0 = off
1 = on
