Installation, connection and commissioning

3.1

Dimensions

3.2

Installation

36
93
Figure: Dimension diagram (in mm)
Figure: DIN rail mounting (left) or screw mounting (right)
90
31.1
47.5
74.5
isoES425_D00214_01_M_XXEN/10.2023
ISOMETER® isoES425
45 70.5
15
