OPERATION VIA WEB INTERFACE

A user may monitor and configure the settings of the PWR-RMT-RBT-C13 and any sensor connected to it using the Web Interface
via any web browser (see page 2 for supported web browsers). To access the Web Interface, connect the PWR-RMT-RBT-C13
to the Ethernet (page 4). Use the Device Discovery Tool (page 7) to setup the network settings. Then, to access the web
interface controls, the user must log in.
Note: In order to view all of the graphics in the Web Interface, the browser's JavaScript must be enabled.
By default, the PWR-RMT-RBT-C13 is configured to dynamically assign network settings received from a DHCP server on the
network it is connected to. (This can be changed to a static IP address to manually enter these settings in the Network Settings on
page 16.) The PWR-RMT-RBT-C13 will search for a DHCP server to automatically assign its IP address each time the unit is
powered up. If the PWR-RMT-RBT-C13 does not find a DHCP server, the address entered into the static IP address field (page
16 -default address shown below) will be used. If a DHCP server on the network has assigned the IP address, use the Device
Discovery Tool to identify the IP address to enter when logging in to the PWR-RMT-RBT-C13.
Note: The computer using the Device Discovery Tool and the NTI Device must be connected to the same subnet in order
for the Device Discovery Tool to work. If no devices are found, the message "No Devices Found" will be displayed.

Log In and Enter Password

To access the web interface, type the current IP address into the address bar of the web browser. (The default IP address when
DHCP is not enabled is shown below):
http://192.168.1.26
A log in prompt requiring a user name and password will appear:
User Name = root
Password = nti
(lower case letters only)
Note: usernames and passwords are case sensitive

Figure 8- Login prompt to access web interface

Note: If you change the root user name or password to something
other than "root" and "nti" (page 30), and you forget either of
these, in order to regain access to the PWR-RMT-RBT-C13, use the
"Restore Defaults" button to reset the Username and Password.
8
