NTI Power Remote Rebooter with C13 Connection
DIN Clip Installation
If you purchased the DIN clip option for your PWR-RMT-RBT-C13 (PWR-RMT-RBT-C13-D), the clips can be attached using the
hardware provided. Pass the screw through the flat washer, then through a hole in the mounting flange, and screw it tightly into
the threaded hole in the clip.
Orient the clips so they allow you to mount the PWR-RMT-RBT-C13-D in the position your
application demands.
Figure 5- DIN clip hardware
Figure 6- DIN Clips Installed
6
