NTI Power Remote Rebooter with C13 Connection
With a successful log in, the "Outputs" page with a menu at left will appear on the screen:
From this initial page, the administrator can use the menu to the left to manage all the functions of the PWR-RMT-RBT-C13.
Function Description
OUTPUTS Monitor the output status (Power Outlet and Digital Outputs), trigger types, and
logic state of the PWR-RMT-RBT-C13
TRIGGER SOURCES View and configure the Trigger Sources that can be set to control the output
status
ADMINISTRATION Configure all system, network and user access settings
SUPPORT Link for downloading a manual
LOGOUT Log the user out of the web interface
From this page you can click "Turn ON" to power the Power Outlet and/or Digital Outputs 1 and 2,
click "Cycle" to cycle the Power Outlet and/or Digital Outputs 1 and 2,
click "Auto" to switch to controlling the outlet using Trigger Source settings, and
click "Edit" to make edits to the output settings and selected Trigger Source settings.
If the Output Control is set to "Auto" (see Figure 11), more information including the status of the triggers that have been set will
be shown as seen in Figure 10 (on the next page).

Figure 9- Initial screen- Outputs state

9
