ENVIROMUX
ENVIROMUX-SRN-A
Adjustable Siren, 114dB
Installation Instruction
The ENVIROMUX-SRN-A Adjustable Siren is used to deter intruders and alert personnel of alert conditions when used in conjunction
with an ENVIROMUX-MINI-LXO, ENVIROMUX-SEMS-16, ENVIROMUX-SEMS-16U or ENVIROMUX-2D/-5D/-16D Server
Environment Monitoring System (SYSTEM). Connect the ENVIROMUX-SRN-A to an output relay on a SYSTEM and configure the
SYSTEM to activate it as needed.
• Emits configurable sound warnings between 79-114dB to deter intruders or alert personnel
• 32 selectable signal tones by dip switch

Installation

1. Mount the ENVIROMUX-SRN-A where desired.
2. Connect the ENVIROMUX-SRN-A to a SYSTEM and the 24VDC power supply (included) as shown in the diagrams below.
3. Go to the Summary Page (under Monitoring) in the web interface.
4. Click on the Output Relay or click on "View" for the relay.
5. The Status page for the output relay will appear. The Output Relay can be controlled manually from this page by selecting Activate
or Deactivate and clicking "Apply Changes", or it can be configured to be part of a sensor group and send alerts to users when its
normal status changes.
