Hardware Installation and Reference Guide
1.2
Product Appearance
Figure 1-1
Front View
Table 1-1
Description of Buttons and Ports on the Front Panel
No.
Item
LAN1/HPoE electrical
1
port
2
LAN2/IoT
3
LAN3/SFP+
Description
Uplink service port for data transmission, 5000Base-T
Ethernet port with auto-negotiation
Support IEEE802.3af/802.3at/802.3bt-complaint PoE
Downlink service port for data transmission, 1000Base-T
Ethernet port with auto-negotiation
Support 802.3af-complaint power supply to external
devices
Uplink service port for data transmission, 10GE SFP port
