Hardware Installation and Reference Guide
Table 1-2 Description of Buttons and Ports on the Rear Panel
No. Item
Console port/Reset
1
button
2 Grounding stud
3 Breathable valve
1.3

Package Contents

Table 1-3 Package Contents
No. Item
1 AP
2 Mounting bracket
3 Support for pole-mounted or
wall-mounted installation
4 M5 x 10 machine screw
5 M6 x 16 machine screw
6 M8 x 20 machine screw
7 M6 x 40 expansion anchor
8
Waterproof PG connector
Description
The port integrates the functions of a console port and a
reset button.
The console port is used to connect with a serial
cable for device management.
The Reset button is used to restart a device or
restore factory settings of the device.
Used to ground the AP.
Used to balance the pressure difference inside and
outside the AP, meeting IP68 rating requirements
Quantity
1
1
1
4
2
2
4
2
4
Product Introduction
Remarks
The rubber plug only has one
hole and adapts to network
