Hardware Installation and Reference Guide
1.2 Product Appearance
The AP provides one 10GETH1/PoE port (RJ45), one multi-extend port (aviation port), one SFP+ port, and one Console
port (RJ45), and two N-type antenna connectors.
Figure 1-1 Product Appearance of the RG-AP680-I
1.3 Bottom View
Figure 1-2 RG-AP680-I Bottom View
1. 5GHz antenna connector 2
Note:
2. Console port and reset button
3. 5GHz antenna connector 1
4. 100/1000/2.5G/5G/10G Base-T auto-sensing Ethernet/PoE port
5. Multi-extend port
6. SFP+ port
Product Overview
·
·
