Hardware Installation and Reference Guide
1

Product Overview

1.1

About the RG-AP180 Access Point

The RG-AP180 is a dual-radio Wi-Fi 6 access point (AP) provided by Ruijie Networks for
general education, higher education, hotel, office, dormitory, and other indoor scenarios. With
simple and pleasant appearance design, the RG-AP180 is easy to deploy without damaging the
wall decoration. It is ideal for wireless network deployment in hotels, dormitories, and other
environments.
Compliant with the latest IEEE 802.11ax standard, the RG-AP180 can work in both 2.4 GHz and
5 GHz frequency bands. The AP delivers a combined data rate of 1.775 Gbps, with up to 575
Mbps in the 2.4 GHz band and 1.2 Gbps in the 5 GHz band. This eliminates the performance
bottleneck. The AP provides five wired ports, including four GE LAN ports and one GE uplink
port, for wired user access. The RG-AP180 provides wireless network security, radio control,
mobile access, Quality of Service (QoS), seamless roaming, and other key features. Working
with Ruijie wireless access controllers (AC), the AP implements wireless user data
forwarding, security, and access control.
The RG-AP180 supports local power supply and power over Ethernet (PoE). Customers can
flexibly select the power supply mode based on the actual site.
1.2

Product Appearance

The RG-AP180 provides two radio connectors and five Ethernet ports. The ports on the rear
panel support 802.3af/at-compliant PoE. The AP also provides one console port, one direct
current (DC) power connector, and one reset hole. The following figures show the product
appearance.
