Proline Promass I 300 PROFINET
Parameter
Concentration
Target mass flow
Carrier mass flow
Endress+Hauser
Prerequisite
For the following order code:
Order code for "Application package",
option ED "Concentration"

The software options currently
enabled are displayed in the
Software option overview
parameter.
With the following conditions:
Order code for "Application package",
option ED "Concentration"

The software options currently
enabled are displayed in the
Software option overview
parameter.
With the following conditions:
Order code for "Application package",
option ED "Concentration"

The software options currently
enabled are displayed in the
Software option overview
parameter.
11.4.2

Totalizer

The Totalizer submenu contains all the parameters needed to display the current
measured values for every totalizer.
Navigation
"Diagnostics" menu → Measured values → Totalizer 1 to n
‣
Totalizer 1 to n
Assign process variable
Totalizer value 1 to n
Totalizer status 1 to n
Totalizer status (Hex) 1 to n
Description
Displays the concentration that is
currently calculated.
Dependency
The unit is taken from the
Concentration unit parameter.
Displays the mass flow that is currently
measured for the target medium.
Dependency
The unit is taken from the Mass flow
unit parameter (→  94).
Displays the mass flow that is currently
measured for the carrier medium.
Dependency
The unit is taken from the Mass flow
unit parameter (→  94).
Operation
User interface
Signed floating-point
number
Signed floating-point
number
Signed floating-point
number
→  146
→  146
→  146
→  146
145
