Commissioning
Parameter
Operating mode
Terminal number
Signal mode
110
Configuring the switch output
Navigation
"Setup" menu → Pulse/frequency/switch output
‣
Pulse/frequency/switch output
1 to n
Operating mode
Terminal number
Signal mode
Switch output function
Assign diagnostic behavior
Assign limit
Assign flow direction check
Assign status
Switch-on value
Switch-off value
Switch-on delay
Switch-off delay
Failure mode
Invert output signal
Parameter overview with brief description
Prerequisite
–
–
–
Description
Define the output as a pulse,
frequency or switch output.
Shows the terminal numbers
used by the PFS output
module.
Select the signal mode for the
PFS output.
Proline Promass I 300 PROFINET
→  110
→  110
→  110
→  111
→  111
→  111
→  111
→  112
→  112
→  112
→  112
→  112
→  112
→  112
Selection / User Factory setting
interface / User
entry
• Pulse Pulse
• Frequency
• Switch
• Not used –
• 24-25 (I/O 2)
• 22-23 (I/O 3)
• Passive Passive
• Active
• Passive NAMUR
