Proline Promass I 300 PROFINET
Remote operation
Service interface
Supported operating tools
Endress+Hauser
→  69
→  70
Different operating tools can be used for local or remote access to the measuring device.
Depending on the operating tool used, access is possible with different operating units and
via a variety of interfaces.
Supported operating Operating unit
tools
Web browser Notebook, PC or tablet
with Web browser
DeviceCare SFE100 Notebook, PC or tablet
with Microsoft Windows
system
FieldCare SFE500 Notebook, PC or tablet
with Microsoft Windows
system
Other operating tools based on FDT technology with a device driver such as DTM/
iDTM or DD/EDD can be used for device operation. These operating tools are available
from the individual manufacturers. Integration into the following operating tools,
among others, is supported:
• Field Device Manager (FDM) by Honeywell →
• FieldMate by Yokogawa →
• PACTWare → www.pactware.com
The associated device description files are available at:
Downloads
Web server
Thanks to the integrated Web server, the device can be operated and configured via a Web
browser and via a service interface (CDI-RJ45) or via a WLAN interface. The structure of
the operating menu is the same as for the local display. In addition to the measured values,
status information on the device is also displayed and allows the user to monitor the status
of the device. Furthermore the device data can be managed and the network parameters
can be configured.
A device that has a WLAN interface (can be ordered as an option) is required for the
WLAN connection: order code for "Display; operation", option G "4-line, illuminated; touch
control + WLAN". The device acts as an Access Point and enables communication by
computer or a mobile handheld terminal.
Supported functions
Data exchange between the operating unit (such as a notebook for example) and the
measuring device:
• Upload the configuration from the measuring device (XML format, configuration
backup)
• Save the configuration to the measuring device (XML format, restore configuration)
• Export event list (.csv file)
• Export parameter settings (.csv file or PDF file, document the measuring point
configuration)
Interface
• CDI-RJ45 service
interface
• WLAN interface
• Ethernet-based
fieldbus (EtherNet/IP,
PROFINET)
• CDI-RJ45 service
interface
• WLAN interface
• Fieldbus protocol
• CDI-RJ45 service
interface
• WLAN interface
• Fieldbus protocol
www.honeywellprocess.com
www.yokogawa.com
Technical data
Additional information
Special Documentation for
device →  262
→  230
→  230
www.endress.com →
