Technical data
Process connections
252
Sensor housing
• Acid and alkali-resistant outer surface
• Stainless steel 1.4301 (304)
Measuring tubes
Grade 9 titanium
Process connections
• Flanges according to EN 1092-1 (DIN 2501) / according to ASME B16.5/ according to
JIS:
• Stainless steel 1.4301 (304)
• Wetted parts: Grade 2 titanium
• All other process connections:
Grade 2 titanium
Available process connections→  252
Seals
Welded process connections without internal seals
Accessories
Protective cover
Stainless steel, 1.4404 (316L)
External WLAN antenna
• Antenna: ASA plastic (acrylic ester-styrene-acrylonitrile) and nickel-plated brass
• Adapter: Stainless steel and nickel-plated brass
• Cable: Polyethylene
• Plug: Nickel-plated brass
• Angle bracket: Stainless steel
• Fixed flange connections:
• EN 1092-1 (DIN 2501) flange
• EN 1092-1 (DIN 2512N) flange
• ASME B16.5 flange
• JIS B2220 flange
• DIN 11864-2 Form A flange, DIN 11866 series A, flange with notch
• Clamp connections:
Tri-Clamp (OD tubes), DIN 11866 series C
• Eccentric clamp connection:
Eccen. Tri-Clamp, DIN 11866 series C
• Thread:
• DIN 11851 thread, DIN 11866 series A
• SMS 1145 thread
• ISO 2853 thread, ISO 2037
• DIN 11864-1 Form A thread, DIN 11866 series A
Process connection materials →  252
