Commissioning
Parameter
Assign limit
Assign diagnostic behavior
Assign status
Switch-off value
Switch-off delay
Switch-on value
114
Prerequisite
The Limit option is selected in
the Relay output function
parameter.
In the Relay output function
parameter, the Diagnostic
behavior option is selected.
In the Relay output function
parameter, the Digital Output
option is selected.
In the Relay output function
parameter, the Limit option is
selected.
In the Relay output function
parameter, the Limit option is
selected.
The Limit option is selected in
the Relay output function
parameter.
Description
Select process variable for limit
function.
Select diagnostic behavior for
switch output.
Select device status for switch
output.
Enter measured value for the
switch-off point.
Define delay for the switch-off
of status output.
Enter measured value for the
switch-on point.
Proline Promass I 300 PROFINET
Selection / User Factory setting
interface / User
entry
• Mass flow Mass flow
• Volume flow
• Corrected volume
*
flow
*
• Target mass flow
*
• Carrier mass flow
• Target volume
*
flow
• Carrier volume
*
flow
• Target corrected
*
volume flow
• Carrier corrected
*
volume flow
• Density
*
• Reference density
*
• Dynamic viscosity
*
• Concentration
• Kinematic
*
viscosity
• Temp.
compensated
*
dynamic viscosity
• Temp.
compensated
kinematic
*
viscosity
• Temperature
• Totalizer 1
• Totalizer 2
• Totalizer 3
• Oscillation
damping
• Pressure
• Application
*
specific output 0
• Application
*
specific output 1
• Index
inhomogeneous
medium
• Index suspended
*
bubbles
• Alarm Alarm
• Alarm or warning
• Warning
• Partially filled pipe Partially filled pipe
detection detection
• Low flow cut off
*
• Profinet Slot 24
*
• Profinet Slot 25
*
• Profinet Slot 26
Signed floating-point Country-specific:
number • 0 kg/h
• 0 lb/min
0.0 to 100.0 s 0.0 s
Signed floating-point Country-specific:
number • 0 kg/h
• 0 lb/min
