Safety instructions
12
2.6
IT security
Our warranty is valid only if the device is installed and used as described in the Operating
Instructions. The device is equipped with security mechanisms to protect it against any
inadvertent changes to the settings.
IT security measures, which provide additional protection for the device and associated
data transfer, must be implemented by the operators themselves in line with their security
standards.
2.7
Device-specific IT security
The device offers a range of specific functions to support protective measures on the
operator' s side. These functions can be configured by the user and guarantee greater in-
operation safety if used correctly. An overview of the most important functions is provided
in the following section.
Function/interface
Write protection via hardware write
protection switch → 12
Access code
(also applies for Web server login or
FieldCare connection) → 13
WLAN
(order option in display module)
WLAN security mode
WLAN passphrase
(password) → 13
WLAN mode
Web server→ 13
CDI-RJ45 service interface → 14
2.7.1
Protecting access via hardware write protection
Write access to the device parameters via the local display, Web browser or operating tool
(e.g. FieldCare, DeviceCare) can be disabled via a write protection switch (DIP switch on
the motherboard). When hardware write protection is enabled, only read access to the
parameters is possible.
Hardware write protection is disabled when the device is delivered → 140.
2.7.2
Protecting access via a password
Different passwords are available to protect write access to the device parameters or access
to the device via the WLAN interface.
Proline Promass I 300 PROFINET
Factory setting
Recommendation
Not enabled.
On an individual basis following risk
assessment.
Not enabled
Assign a customized access code during
(0000).
commissioning.
Enabled.
On an individual basis following risk
assessment.
Enabled (WPA2-
Do not change.
PSK)
Serial number
Assign an individual WLAN passphrase during
commissioning.
Access Point
On an individual basis following risk
assessment.
Enabled.
On an individual basis following risk
assessment.
–
On an individual basis following risk
assessment.
Endress+Hauser
