12.10 Event Logbook; 12.10.1 Reading Out The Event Logbook - Endress+Hauser Proline Promass I 300 PROFINET Operating Instructions Manual

Proline Promass I 300 PROFINET
Endress+Hauser
 30 Taking the example of the local display
To call up the measures to rectify a diagnostic event:
• Via local display →  161
• Via Web browser →  162
• Via "FieldCare" operating tool →  163
• Via "DeviceCare" operating tool →  163

12.10 Event logbook

12.10.1 Reading out the event logbook

A chronological overview of the event messages that have occurred is provided in the
Events list submenu.
Navigation path
Diagnostics menu → Event logbook submenu → Event list
 31 Taking the example of the local display
• A maximum of 20 event messages can be displayed in chronological order.
• If the Extended HistoROM application package (order option) is enabled in the device,
the event list can contain up to 100 entries .
The event history includes entries for:
• Diagnostic events →  167
• Information events →  220
In addition to the operation time of its occurrence, each event is also assigned a symbol
that indicates whether the event has occurred or is ended:
• Diagnostic event
• : Occurrence of the event
• : End of the event
• Information event
: Occurrence of the event
To call up the measures to rectify a diagnostic event:
• Via local display →  161
• Via Web browser →  162
• Via "FieldCare" operating tool →  163
• Via "DeviceCare" operating tool →  163
For filtering the displayed event messages →  220
/ ../Diagnose list
Diagnostics
F273 Main electronic
Diagnostics 2
Diagnostics 3
/ ../Eventlist
I1091 Config. change
I1157 Mem.err. ev.list
0d01h19m10s
F311 Electr. failure
Diagnostics and troubleshooting
F
A0014006-EN
A0014008-EN
219
