Endress+Hauser Proline Promass I 300 PROFINET Operating Instructions Manual page 260

Technical data
Diagnostics functions
Heartbeat Technology
Concentration
260
local Endress+Hauser sales center or on the product page of the Endress+Hauser website:
www.endress.com.
Detailed information on the application packages:
Special Documentation for the device →  262
Package Description
Extended HistoROM Comprises extended functions concerning the event log and the activation of the
measured value memory.
Event log:
Memory volume is extended from 20 message entries (standard version) to up to
100 entries.
Data logging (line recorder):
• Memory capacity for up to 1000 measured values is activated.
• 250 measured values can be output via each of the 4 memory channels. The
• Measured value logs can be accessed via the local display or operating tool e.g.
Package Description
Heartbeat Verification Heartbeat Verification
+Monitoring Meets the requirement for traceable verification to DIN ISO 9001:2008 Chapter
7.6 a) "Control of monitoring and measuring equipment".
• Functional testing in the installed state without interrupting the process.
• Traceable verification results on request, including a report.
• Simple testing process via local operation or other operating interfaces.
• Clear measuring point assessment (pass/fail) with high test coverage within the
• Extension of calibration intervals according to operator' s risk assessment.
Heartbeat Monitoring
Continuously supplies data, which are characteristic of the measuring principle, to
an external condition monitoring system for the purpose of preventive
maintenance or process analysis. These data enable the operator to:
• Draw conclusions - using these data and other information - about the impact
• Schedule servicing in time.
• Monitor the process or product quality, e.g. gas pockets.
Package Description
Concentration Calculation and outputting of fluid concentrations
The measured density is converted to the concentration of a substance of a binary
mixture using the "Concentration" application package:
• Choice of predefined fluids (e.g. various sugar solutions, acids, alkalis, salts,
• Common or user-defined units (°Brix, °Plato, % mass, % volume, mol/l etc.) for
• Concentration calculation from user-defined tables.
recording interval can be defined and configured by the user.
FieldCare, DeviceCare or Web server.
framework of manufacturer specifications.
process influences (such as corrosion, abrasion, buildup etc.) have on the
measuring performance over time.
ethanol etc.)
standard applications.
Proline Promass I 300 PROFINET
Endress+Hauser
