Commissioning
Parameter
Operating mode
Terminal number
Signal mode
Assign pulse output 1 to n
Pulse scaling
Pulse width
Failure mode
Invert output signal
* Visibility depends on order options or device settings
106
Parameter overview with brief description
Prerequisite
–
–
–
The Pulse option is selected in
the Operating mode
parameter parameter.
The Pulse option is selected in
the Operating mode
parameter (→  105) and a
process variable is selected in
the Assign pulse output
parameter (→  106).
The Pulse option is selected in
the Operating mode
parameter (→  105) and a
process variable is selected in
the Assign pulse output
parameter (→  106).
The Pulse option is selected in
the Operating mode
parameter (→  105) and a
process variable is selected in
the Assign pulse output
parameter (→  106).
–
Description
Define the output as a pulse,
frequency or switch output.
Shows the terminal numbers
used by the PFS output
module.
Select the signal mode for the
PFS output.
Select process variable for
pulse output.
Enter quantity for measured
value at which a pulse is
output.
Define time width of the
output pulse.
Define output behavior in
alarm condition.
Invert the output signal.
Proline Promass I 300 PROFINET
Selection / User Factory setting
interface / User
entry
• Pulse Pulse
• Frequency
• Switch
• Not used –
• 24-25 (I/O 2)
• 22-23 (I/O 3)
• Passive Passive
• Active
• Passive NAMUR
• Off Off
• Mass flow
• Volume flow
• Corrected volume
*
flow
*
• Target mass flow
*
• Carrier mass flow
• Target volume
*
flow
• Carrier volume
*
flow
• Target corrected
*
volume flow
• Carrier corrected
*
volume flow
Positive floating Depends on country
point number and nominal
diameter
0.05 to 2 000 ms 100 ms
• Actual value No pulses
• No pulses
• No No
• Yes
