Product description
The device consists of a transmitter and a sensor.
The device is available as a compact version:
The transmitter and sensor form a mechanical unit.
3.1
Product design
1
1
Important components of a measuring device
1
Connection compartment cover
2
Display module
3
Transmitter housing
4
Electronics compartment cover
5
Sensor
2
3
