Removal and Replacement
Removing and Replacing Covers
Step 5. Place the cover in a safe location.
Figure 6-2 Top Cover Removed
Retaining Screw

Replacing the Top Cover

Step 1. Orient the cover according to its position on the chassis.
Step 2. Slide the cover into position using a slow, firm pressure to properly seat the cover.
Step 3. Tighten the blue retaining screws securing the cover to the chassis.
143
Chapter 6
