Removal and Replacement

Removing and Replacing the Core I/O

Removing and Replacing the Core I/O
The core I/O is located in the rear of the chassis. There can be two core I/O boards installed in the server, core
I/O 0 and core I/O 1. The core I/O can be replaced while standby power is applied. However, the operating
system on the nPartition must be shut down to replace the CRU.
CAUTION Observe all ESD safety precautions before attempting this procedure. Failure to follow ESD
safety precautions could result in damage to the server.
Figure 6-11 Core I/O Location
152
Core I/O Card 0
Core I/O Card 1
