Cabling and Power Up

Accessing the Management Processor via a Web Browser

Accessing the Management Processor via a Web Browser
Web browser access is an embedded feature of the management processor (MP). The Web browser allows
access to the server via the LAN port on the core I/O card. MP configuration must be done from an ASCII
console.
NOTE The MP has a separate LAN port from the system LAN port. It requires a separate LAN drop,
IP address, and networking information from that of the port used by HP-UX.
Before starting this procedure, the following information is required:
• IP address for the MP LAN
• Subnet mask
• Gateway address
• Hostname (this is used when messages are logged or printed)
To configure the LAN port for a Web browser, perform the following steps:
Step 1. Connect to the MP using a serial connection.
Step 2. Configure the MP LAN. Refer to "Configuring LAN Information for the MP".
Step 3. Type CM to enter the Command Menu.
Step 4. Type at the MP:CM> prompt to display and set MP remote access.
SA

Figure 4-15 Example sa Command

92
Chapter 4
