11.11 Mode 11: Agent Release, Single Hazard, Cross-zoned,
Combined Release
Out1 Signal Steady
Out2 Signal Escalating
Out3 Rel. Releasing
Out4 Rel. Releasing
RLS TMR 1 Started
RLS Tmr 1 Interrupted
RLS Tmr 1 Cancelled
RLS Tmr 2 Started
RLS Tmr 2 Interrupted
RLS Tmr 2 Cancelled
11.11.1 Zone Configuration
• Detection Zone -1: Alarm (Hazard Area1, cross-zoned)
• Detection Zone -2: Alarm (Hazard Area1, cross-zoned)
• Detection Zone -3: Alarm (Pressure Switch or Water-flow)
• Detection Zone -4: Supervisory (Default non-latching)
• Detection Zone -5: Abort Switch
• Detection Zone -6: Manual Release
• NAC -1: Signal, indicate the Hazard Area1 status
• NAC -2: Signal, indicate the Hazard Area1 status
• RAC -3: Releasing Circuit
• RAC -4: Releasing Circuit
11.11.2 Hazard Configuration
• Default Release Timer Value:
• Default Manual Release Delay:
• Default Abort Delay Type:
• Soak Timer Value:
11.11.3 NAC Configuration
• Default Escalating NAC code of Hazard Area State:
• Hazard Idle: Off
• Hazard Alert: Steady
• Hazard Alarm: 60BPM
• Hazard Release: Steady
• Default NAC code of supervisory is 20 BPM
80
Detection Zones
Z1 Z2 Z3 Z4
Alm Alm WF Supv
X (X)
60 seconds
0 seconds
Standard UL
0 seconds (continuous)
Phantom Zones
Z5 Z6 Zp1 Zp2
AB MR Z1+Z2 Z3+Z4
X
X X
X
X
X
X
X
Release Timers
RT1 RT2
Exp Exp
X
X
