FA-300 Series
LED Fire Alarm Control Panel
Installation and Operation Manual
Advan ced Life Safet y Solut ions
LAMP
AC
TEST
ON
REMOTE
COMMON
TROUBLE
ALARM
CPU
COMMON
FAULT
SUPERVISORY
GROUND
COMMON
FAULT
TROUBLE
BATTERY
TROUBLE
SIGNAL
SYSTEM
SILENECE
RESET
FIRE
AUXILIARY
DRILL
DISCONNECT
LAMP
BUZZER
SILENCE
TEST
MENU
INFO
ZONE DISCONNECT
ZONE DISCONNECT
nt ro l Pa ne l
Fi re Al ar m Co
LT-905 Rev. 8.1
November 2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FA-301-12LDW and is the answer not in the manual?

Questions and answers

Related Manuals for Mircom FA-301-12LDW

Summary of Contents for Mircom FA-301-12LDW

  • Page 1 FA-300 Series LED Fire Alarm Control Panel Advan ced Life Safet y Solut ions LAMP TEST REMOTE COMMON TROUBLE ALARM COMMON FAULT SUPERVISORY GROUND COMMON FAULT TROUBLE BATTERY TROUBLE SIGNAL SYSTEM SILENECE RESET FIRE AUXILIARY DRILL DISCONNECT LAMP BUZZER SILENCE TEST MENU INFO...

  • Page 3: Table Of Contents

    FA-300 Series LED Version Installation and Operation Manual Contents List of Figures and Tables....................... iii Industry Canada and FCC Notice ................... 1 Introduction ..........................2 Overall Features ........................2 Conventions ..........................3 Circuits ..........................3 Zone............................3 Display Points ........................3 Wiring Styles .........................
  • Page 4 Contents Circuit (zone) disconnect buttons..................32 Common Relays........................33 Circuit Types ........................33 Evacuation codes......................... 35 Single Stage Operation ......................36 Two-stage Operation......................36 Supported Protocols/Devices ....................38 Synchronous Strobes......................38 System Sensor’s i3 Devices....................38 Configuration and CFG-300 LCD Service Tool ..............40 Entering the Passcode ......................
  • Page 5 FA-300 Series LED Version Installation and Operation Manual List of Figures and Tables Figures Figure 1: Box dimensions, surface mount.................. 9 Figure 2: Box dimensions, semi-flush mounting and trim ring ........... 10 Figure 3: Installation of Adder Modules..................11 Figure 4: Main Fire Alarm Board cable connector and jumper settings ........12 Figure 5: ICAC-306 Input Class-A Converter Adder Module .............

  • Page 7: Industry Canada And Fcc Notice

    Contact your telephone company if you have any questions about your phone line. In the event repairs are ever needed on the Communicator, they should be performed by Mircom Technologies Ltd. or an authorized representative of Mircom Technologies Ltd. For information contact Mircom Technologies Ltd. at the address and phone numbers shown on the back page of this document.

  • Page 8: Introduction

    Introduction Introduction Mircom's FA-300 Series Fire Alarm Control Panel is a Digital Signal Processor (DSP)-based fire panel. The FA-300 provides a maximum of 12 supervised Class B or A (Style B or D) Initiating circuits, and maximum four supervised Class B or A (Style Y or Z) indicating circuits. All circuits are supervised for opens and ground faults, and indicating circuits are supervised for shorts.

  • Page 9: Conventions

    FA-300 Series LED Version Installation and Operation Manual Conventions Circuits Refers to an actual electrical interface for Initiating (Detection) and Indicating (Signal) or Relays Zone Is a logical concept for a Fire Alarm Protected Area, and will consist of at least one Circuit. Often the terms Zone and Circuit are used interchangeably, but in this Manual the term Circuit is used.

  • Page 10: System Components

    Enertech model SA12120) batteries (two required). 12 Zone Fire Alarm with LED display (white FA-301-12LW door, black box). Same as FA-301-12LDW except without dialer. 12 Zone Fire Alarm with LED display (red door, FA-301-12LR black box). Same as FA-301-12LDR except...

  • Page 11: Relay Module: 12 Relays

    FA-300 Series LED Version Installation and Operation Manual 8 Zone Fire Alarm Control Panel with LED display (white door, black box). 8 Class B (Style B) Initiating circuits, and four Power Limited Class B (Style Y) Indicating circuits (up to1.70 amperes each, 5 amperes total). Two six zone ICAC-306 Input Class A converter adder modules may be used for Class A (Style D) wiring of Initiating circuits.

  • Page 12: Remote Annunciator

    System Components Remote Annunciator Model Description Remote Annunciator RAM- module, LCD display, 300LCDW S Y S T E M N O R M A L white painted box 1 8 : 0 1 M O N 2 0 0 3 - 0 4 - 0 5 A.C.

  • Page 13: Input Class A Converter: Six Circuits

    FA-300 Series LED Version Installation and Operation Manual Input Class A converter: Six Circuits Model Description Input Class A converter Module (six circuits). This ICAC-306 module has built in Active End-of-Line resistors. Output Class A converter: four circuits Model Description Output Class A converter module (four OCAC-304 circuits)

  • Page 14: Ram-216 Remote Annunciator

    System Components RAM-216 Remote Annunciator Model Description A.C. COMMON SIGNAL TROUBLE SILEBCE BUZZER SIGNAL RAM-216 16 Zone remote annunciator SILENCE SILENCE SWITCH ENABLE LAMP SYSTEM TEST RESET FIRE ALARM ANNUNCIATOR Additional Fire Alarm System Accessories Model: RAM-208 Eight Zone Remote Annunciator (ULC and ULI Approved) Model: RTI-1 Remote Trouble Indicator...

  • Page 15: Mechanical Installation

    FA-300 Series LED Version Installation and Operation Manual Mechanical Installation Installing the Enclosure Install the FA-300 Series Fire Alarm Panel enclosure as shown below for the twelve-, eight-, and six-zone models. Mount enclosure surface mount using the four mounting holes, as shown and the screws provided. Figure 1: Box dimensions, surface mount 11"...

  • Page 16: Figure 2: Box Dimensions, Semi-Flush Mounting And Trim Ring

    Mechanical Installation Figure 2: Box dimensions, semi-flush mounting and trim ring 11" 1.5" PLACE FA-UNIV-TRB TRIM RING OVER BACKBOX 17" 20.5" 26" Adhere trim ring to 28.5" wall surface around FA-300 backbox. 5.4" 3.5" 1" 14.5" 3.5" is the maximum depth for semi-flush 1"...

  • Page 17: Installing The Adder Modules

    FA-300 Series LED Version Installation and Operation Manual Installing the Adder Modules FA-300 Series Fire Alarm panels come pre-assembled with all components and boards except for Adder Modules. Module installation locations are shown below. Refer to Figure 4 on the next page for Jumper or DIP Switch settings and see Wiring Tables and Information for wiring specifications.

  • Page 18: Cable And Jumper Connections For Main Board And Adder Modules

    Cable and Jumper Connections for Main Board and Adder Modules Cable and Jumper Connections for Main Board and Adder Modules Main Fire Alarm Board Figure 4: Main Fire Alarm Board cable connector and jumper settings For PC programming use UIMA JW6-Open all the time interface module not UL-864 or ULC-S527 listed.

  • Page 19: Icac-306 Input Class-A Converter Adder Module

    FA-300 Series LED Version Installation and Operation Manual Table 1: Connectors and Jumpers on the Main Fire Alarm Board Cable from P1 of the PR-300 Polarity Reversal and City Tie Module connects here. Otherwise not used. Cable from connector P1 of the RM-312 or RM-306 Relay Adder Module connects here. Otherwise not used.

  • Page 20: Ocac-304/302 Output Class-A Converter Adder Module

    Cable and Jumper Connections for Main Board and Adder Modules OCAC-304/302 Output Class-A Converter Adder Module Figure 6: OCAC-304/302 Output Class-A Converter Adder Module mounting hole for #6-32 screws mounting hole for #6-32 screws OCAC-304 OCAC-302 mounting hole for #6-32 screws mounting hole for #6-32 screws Indicating circuits must be wired from the OCAC-304/302 to the main Fire Alarm board.

  • Page 21: Rm-306 Six Relay Adder Module

    FA-300 Series LED Version Installation and Operation Manual Figure 8: RM-312/306 Relay programming ZONE JUMPER installed: turns ON relay when the zone (1) is active LOGICAL OR WITH ADJACENT ZONE removed: does not turn ON the relay when jumper installed: this relay 1 works in zone (1) is active conjunction with relay 2 Default: Jumper is installed...

  • Page 22: Polarity Reversal And City Tie Module (Model Pr-300)

    Cable and Jumper Connections for Main Board and Adder Modules Polarity Reversal and City Tie Module (Model PR-300) Figure 10: Polarity reversal and city tie module Mounting hole for #6-32 screws Mounting hole for #6-32 screws The following hardware configuration must be performed before installing the PR-300. Table 2: PR-300 jumper settings Cable connects to P5 on the Main Fire Alarm Board Cut this jumper for Trouble transmission.

  • Page 23: Field Wiring

    FA-300 Series LED Version Installation and Operation Manual Field wiring Main Fire Alarm Board Field Wiring Wire devices to the terminals as shown in the figures that follow. Refer to the Wiring Tables for wire gauges and to Appendix A for specifications. CAUTION: Do not exceed power supply ratings.

  • Page 24: Figure 12: Initiating Circuit- Class A Or Style D Wiring

    Field wiring Figure 12: Initiating circuit– Class A or Style D wiring DCAC-306 CLASS A ICAC CONVERTER MODULE STYLE D WIRING FIRE ALARM MAIN BOARD INITIATING CIRCUIT - 1 ALARM ZONE INITIATING CIRCUIT #1 INITIATING STYLE D CIRCUIT #2 WIRING INITIATING CIRCUIT - 2 SUPERVISORY...

  • Page 25: Figure 14: Indicating Circuit -Class A Or Style Z Wiring

    FA-300 Series LED Version Installation and Operation Manual Figure 14: Indicating circuit –Class A or Style Z wiring OCAC-304 CLASS A STYLE Y CONVERTER MODULE WIRING FIRE ALARM MAIN BOARD INDICATING CIRCUIT 1 INDICATING CIRCUIT #1 INDICATING CIRCUIT #2 STYLE Y WIRING 2 MORE INDICATING INDICATING...

  • Page 26: Relay Adder Module Wiring

    Field wiring Dialer Wiring If you have Fire Alarm Panel Models FA-301-12LDW, FA-301-12LDR, and FA-301-8LDW there is a dialer on board and terminals marked Line 1 and Line 2 must be wired as shown in Figure 16 below. Figure 16: Dialer wiring...

  • Page 27: Figure 18: Relay Per Zone (Rm-306) Terminal Connection

    FA-300 Series LED Version Installation and Operation Manual Figure 18: Relay per zone (RM-306) Terminal connection RM-306 6 RELAY ADDER MODULE NORMALLY OPEN OR NORMALLY OPEN RELAY NORMALLY CLOSED CONNECTION CIRCUIT #1 CONNECTION IS NO/NC SELECTED BY JUMPER NORMALLY CLOSE ON RELAY BOARD.

  • Page 28: Polarity Reversal And City Tie Module (Pr-300) Wiring

    Field wiring Polarity Reversal and City Tie Module (PR-300) Wiring Wire PR-300 Polarity Reversal and City Tie Module (if used) as shown in Figure 19, below. See Appendix A for module specifications. Power Limited cable type FPL, FPLR or FPLP must be used. For USA installation, the installer must use Atlantic Scientific (Tel: 407-725-8000), Model #24544 Protective Device, or similar UL-Listed QVRG secondary protector, as shown.

  • Page 29: Power Supply Connection

    FA-300 Series LED Version Installation and Operation Manual Power supply connection The power supply is part of the Main Chassis. The ratings are: Type Rating Electrical Input rating 120VAC, 60Hz, 3A\ 240 VAC, 50 Hz, 1.5A fuse Power supply total current 6A maximum Battery fuse on Main 10A, slow blow micro fuse...

  • Page 30: Wiring Tables And Information

    Field wiring Wiring Tables and Information Table 3: Initiating Circuit Wiring Wire gauge Maximum wiring run to last device Feet Meters 2990 4760 1450 7560 2300 12000 3600 19000 5800 30400 9200 Notes: • For Class A the maximum wiring run to the last device is divided by two. •...

  • Page 31: Auxiliary Power (Unregulated)

    FA-300 Series LED Version Installation and Operation Manual Auxiliary Power (unregulated) This unregulated supply is not supervised. This supply is rated at 24VDC/1.7A max. If there is a short on this circuit, the auxiliary power does not recover automatically when the short is removed. The main power must be disconnected, then reconnected and the panel reset to re-establish the auxiliary power supply.

  • Page 32: System Checkout

    System Checkout System Checkout Before turning the power “ON” To prevent sparking, do not connect the batteries. Connect the batteries after powering the system from the main AC supply. 1. Check that all modules are installed in the proper location with the proper connections. 2.

  • Page 33: Indicators, Controls And Operations

    FA-300 Series LED Version Installation and Operation Manual Indicators, Controls and Operations Refer to Figure 21 below for LED Indicator and Control Button locations. Figure 21: LED indicators and control buttons WALK A.C. TE S T RE MO TE CO MMO N TRO UBLE ALARM CO MMO N...

  • Page 34: Common Indicators

    Note that each display is supplied with laser printer printable paper labels for sliding into the plastic label template on the panel. For the Main Display, the paper label is Mircom# NP-2005; this includes English and French versions. Note: There are different labels for Two Stage operation.
  • Page 35 FA-300 Series LED Version Installation and Operation Manual Fire Drill LED The amber Fire Drill Indicator illuminates steadily while Fire Drill is active. Acknowledge LED If the Panel is configured as a two-stage system, the Acknowledge Indicator flashes amber at the Fast Flash Rate while the Auto General Alarm Timer is timing out.

  • Page 36: Alarm Circuit Indicators

    Indicators, Controls and Operations Alarm Circuit Indicators This operation applies to Initiating Circuits configured as Verified Alarm, Non-Verified Alarm, Water flow Alarm, Sprinkler Alarm, or General Alarm Circuits. The following table summarizes the indications at different events. Event Circuit Trouble LED Configuration Flashes at the trouble rate Verified Alarm...

  • Page 37: Trouble-Only Circuit Indicators

    FA-300 Series LED Version Installation and Operation Manual Trouble-only Circuit Indicators This operation applies to initiating circuits configured as Trouble-Only Circuits. The following table summarizes the indications in response to different events. Event Circuit Trouble LED Configuration Flashes at the trouble rate Open circuit or (Style D)/(Class A) trouble (amber) Flashes at the trouble rate...

  • Page 38: Circuit (Zone) Disconnect Buttons

    Indicators, Controls and Operations Fire Drill Button The Fire Drill button activates all Non-Disconnected Indicating Circuits, but does not transmit any Alarms via the City Tie, Common Alarm Relay or Auxiliary Alarm Relay. Fire Drill activates the signals in the evacuation code programmed.

  • Page 39: Common Relays

    FA-300 Series LED Version Installation and Operation Manual When an Initiating Circuit Disconnect pushbutton is returned to the normal state (by pressing it again in order to un- bypass the circuit), the panel checks the state of the circuit. If the circuit is active, the Status Indicator flashes for 10 seconds at the Fast Rate without processing the input.
  • Page 40 Indicators, Controls and Operations Water Flow Alarm (Water flow Sensors) Water Flow Alarms are identical to normal Non-Verified Alarms except that any indicating circuits programmed to these circuits (all are by default) are Non-Silenceable. Also, if Water Flow Retard Operation is enabled, these circuits are sampled every one second.

  • Page 41: Evacuation Codes

    FA-300 Series LED Version Installation and Operation Manual Silenceable Strobe Silenceable strobes will be silenced when the “signal silence” key is pressed. For synchronous strobes see supported protocol/devices section. (NB: Strobes do not support any code pattern.) Non-Silenceable Strobes Non-Silenceable Strobes will not be silenced when the “signal silence” key is pressed. For synchronous strobes see supported protocol/devices section.

  • Page 42: Single Stage Operation

    Indicators, Controls and Operations Single Stage Operation In a single stage system all alarm inputs are treated in a similar manner. Alarm inputs include any of the following: Non-Verified Alarm, Verified Alarm, Sprinkler Alarm, Water flow Alarm, and General Alarm Circuits. If any of these alarm inputs occur when the panel is not already in alarm, the following occurs: •...
  • Page 43 FA-300 Series LED Version Installation and Operation Manual • If the panel is not already in General Alarm and if the Acknowledge Indicator is ON steady, indicating that the Auto General Alarm Timer has been acknowledged, the timer is restarted and the Acknowledge LED is extinguished.

  • Page 44: Supported Protocols/Devices

    Supported Protocols/Devices Synchronous Strobes The synchronous strobe models that are supported by the FA-300 panel include Mircom models FHS-240 and FS-240. A separate compatibility list is available for different supported models. Strobes can be configures as normal (e.g. not synchronized or any of the above; see configuration section). Any selection made is system-wide (e.g.
  • Page 45 FA-300 Series LED Version Installation and Operation Manual Open circuit trouble If the loop is broken the panel shows open loop trouble. The panel can still communicate with the devices depending upon where the open occurs. Z o n e - 1 O p e n T r b .

  • Page 46: Configuration And Cfg-300 Lcd Service Tool

    Configuration and CFG-300 LCD Service Tool Configuration and CFG-300 LCD Service Tool There are three methods of configuring the FA-300 LED Series Fire Alarm Panels: 1. Using the CFG-300 LCD Tool (see further documentation packaged with CFG-300 for configuration informa- tion).

  • Page 47: Entering The Passcode

    FA-300 Series LED Version Installation and Operation Manual Entering the Passcode The programming section is passcode protected. The following screen shows the message that is displayed to enter the passcode. The maximum allowable passcode is ten digits long, and permits numerical values only. Press the “ENTER”...

  • Page 48: Fa-300 Config (Command-Menu)

    Configuration and CFG-300 LCD Service Tool 1. FA-300 CONFIG (Command-Menu) The following is a detailed description of the FA-300 configuration menu. -FA-300 Config- 1. Features 2. Inp. Zone 3. I3 Zones 4. Opt. Zone 5. Correlation 6. Inp Zone Label 7.
  • Page 49 FA-300 Series LED Version Installation and Operation Manual How to Use the Keypad to Program the FA-300 1. Press MENU to enter the command menu. 2. Select a Command Menu option by pressing ENTER. The corresponding submenu will display. 3. Use the up and down arrow buttons to scroll through the submenu. 4.
  • Page 50 Configuration and CFG-300 LCD Service Tool Command Menu/FA-300 Config/Features/ Use this function to inhibit the [X] DISABLE->Default “SIGNAL SILENCE” switch for a 6.Signal-Silence Inhibit timer [ ] 10 SEC desired length of time. This time period should expire before the [ ] 20 SEC S i g - S i l .
  • Page 51 The [X] NORMAL ->Default selection is system-wide and S t r o b e T y p e [ ] MIRCOM applies to all indicating circuits configured as strobes. For [ ] FARADY [ X ] N O R M A L “NORMAL”...
  • Page 52 Configuration and CFG-300 LCD Service Tool Command Menu/FA-300 Config/Features/ 18. Auto General Alarm Timer [X] DISABLE->Default [ ] 5 Min This function is used for two- [ ] 10 Min stage systems only. This A u t o G e n - A l a r m T i m e r function sets the time period for [ ] 15 Min automatic evacuation.
  • Page 53 FA-300 Series LED Version Installation and Operation Manual Command Menu-->FA-300 Config Note: Refer to How to Use the Keypad to Program the FA-300 on page 43 for detailed instructions on making menu selections. Inp Zone I n i t i a t i n g Z o n e 1 Z o n e - 1 2 Z o n e - 2 1 2 Z o n e 1 2...
  • Page 54 Configuration and CFG-300 LCD Service Tool Command Menu-->FA-300 Config Note: Refer to How to Use the Keypad to Program the FA-300 on page 43 for detailed instructions on making menu selections. Opt Zone I n d i c a t i n g Z o n e 1 N A C - 1 2 N A C - 2 3 N A C - 3...
  • Page 55 FA-300 Series LED Version Installation and Operation Manual Command Menu-->FA-300 Config Note: Refer to How to Use the Keypad to Program the FA-300 on page 43 for detailed instructions on making menu selections. Inp Zone Msg I n i t i a t i n g Z o n e 1 Z o n e - 1 2 Z o n e - 2 1 2 Z o n e 1 2...
  • Page 56 Configuration and CFG-300 LCD Service Tool Command Menu-->FA-300 Config Note: Refer to How to Use the Keypad to Program the FA-300 on page 43 for detailed instructions on making menu selections. Opt Zone Label I n d i c a t i n g Z o n e 1 N A C - 1 2 N A C - 2 3 N A C - 3...

  • Page 57: Config Info

    FA-300 Series LED Version Installation and Operation Manual 2. Config Info (Command-Menu Note: Refer to How to Use the Keypad to Program the FA-300 on page 43 for detailed instructions on making menu selections. Configuration type will show how the panel was configured. Configuration type: “Factory default”...

  • Page 58: Set Time (Command-Menu)

    Configuration and CFG-300 LCD Service Tool 3. Set Time (Command-Menu) Note: Refer to How to Use the Keypad to Program the FA-300 on page 43 for detailed instructions on making menu selections. 1 Daylight Save 2 Time Clock 3 Compensation Command Menu/Set time Date 1.

  • Page 59: Change Password (Command-Menu)

    FA-300 Series LED Version Installation and Operation Manual 4. Change password (Command-Menu) Note: Refer to How to Use the Keypad to Program the FA-300 on page 43 for detailed instructions on making menu selections. Enter new passcode Re-enter passcode If the passcode does not match, the Use this function to change the pass-code.

  • Page 60: Clear Event Log (Command-Menu)

    Configuration and CFG-300 LCD Service Tool 6. Clear Event Log (Command-Menu) Note: Refer to How to Use the Keypad to Program the FA-300 on page 43 for detailed instructions on making menu selections. -Select Log- 1 Alarm Log 2 General Log 3 All Logs Select the type of log to clear.

  • Page 61: Walk Test (Command-Menu)

    FA-300 Series LED Version Installation and Operation Manual 7. Walk Test (Command-Menu) Note: Refer to How to Use the Keypad to Program the FA-300 on page 43 for detailed instructions on making menu selections. Walk-Test allows an installer to verify the initiating circuit wiring in a system. When walk test is selected, the following screen confirms the operation: P e r f o r m t h e w a l k t e s t ? Y...

  • Page 62: I3 Loop Test (Command-Menu)

    Configuration and CFG-300 LCD Service Tool 8. i Loop Test (Command-Menu) Note: Refer to How to Use the Keypad to Program the FA-300 on page 43 for detailed instructions on making menu selections. The i maintenance test is designed to test the devices on i zone.

  • Page 63: Dialer Config (Command-Menu)

    FA-300 Series LED Version Installation and Operation Manual 9. Dialer Config (Command-Menu) Note: Refer to How to Use the Keypad to Program the FA-300 on page 43 for detailed instructions on making menu selections. The following illustration shows the dialer configuration menu. This menu will show up only if there is a built-in dialer on the main board.
  • Page 64 Configuration and CFG-300 LCD Service Tool Command Menu/Dialer Config/Account Info Use this function to set the telephone number of the 2.Account#1 Telephone Number monitoring station. The maximum # of digits allowed is 19 including “,” and numerals. A c c o u n t # 1 T e l n u m : The “,”...
  • Page 65 FA-300 Series LED Version Installation and Operation Manual Command Menu-->Dialer Config Note: Refer to How to Use the Keypad to Program the FA-300 on page 43 for detailed instructions on making menu selections. Telephone Line - T e l e p h o n e L i n e - 1 L i n e 1 D i a l t y p e 2 L i n e 2 D i a l t y p e 3 L i n e 1 D i a l t o n e...
  • Page 66 Configuration and CFG-300 LCD Service Tool Command Menu-->Dialer-Config Note: Refer to How to Use the Keypad to Program the FA-300 on page 43 for detailed instructions on making menu selections. Report Options - Report Options - 1 Alarm Prio. 2 Trouble Prio. 3 Supv.
  • Page 67 FA-300 Series LED Version Installation and Operation Manual Command Menu/Dialer-Config/Report Options 5.Fire Panel type Do not change this function; [X] FA-300 Panel->Default keep it as default. [ ] FA-1000 Panel For factory use only. F i r e P a n e l T y p e : [ ] FX-2000 Panel [ X ] F A - 3 0 0 P a n e l Command Menu/Dialer-Config/Report...
  • Page 68 Configuration and CFG-300 LCD Service Tool Command Menu/Dialer-Config/Time Use this function to set the test Parameter report date for the cell phone setup. If the date is set to 0, 2.Cellular report date this means there is no test reporting for cell phone or the Cellular Report Date phone line is a regular line.

  • Page 69: Test Dialer (Command-Menu)

    FA-300 Series LED Version Installation and Operation Manual Command Menu-->Dialer-Config Note: Refer to How to Use the Keypad to Program the FA-300 on page 43 for detailed instructions on making menu selections. Dialer Enable/Disable D i a l e r E n a / D i s The dialer is enabled by default.
  • Page 70 Configuration and CFG-300 LCD Service Tool Dialer Test Messages The following messages will display during the test processes of Lines #1 and #2. The messages that will appear depend on the status of the dialer and the test results that are found. The dialer is checking the line for voltage.

  • Page 71: Exit (Command-Menu)

    FA-300 Series LED Version Installation and Operation Manual 11. Exit (Command-Menu) Pressing, “ENTER” after selecting “Exit“ from the menu will return the panel to normal LCD operation. CFG-300 LCD Service tool operation If an LCD service tool is connected to the panel, you will only be able to view the latest message–you cannot scroll through them.
  • Page 72 Configuration and CFG-300 LCD Service Tool AC Power Fail The AC power fail trouble is generated when the power drops below the UL specified value. The trouble is restored when the power returns to the normal value. T ro u b le c o d e T ro u b le In fo T ro u b le T yp e A C P o w e r F a i l...
  • Page 73 FA-300 Series LED Version Installation and Operation Manual Remote Annunciator Troubles related to the annunciator can have two possibilities: either the main panel and annunciator failed to communicate with each other, or an un-configured remote annunciator is responding to the main panel. In both the cases, the following trouble message is displayed: T ro u b le in fo T ro u b le T yp e...
  • Page 74 Configuration and CFG-300 LCD Service Tool Supervised Aux-supply The supervised aux-supply is supervised for shorts. When a short is detected on supervised aux-supply the power is cut off and a trouble message is generated. Press the system “RESET” key to restore the power the system. If the short is removed, the panel will return to normal;...

  • Page 75: Appendix A: Compatible Receivers

    FA-300 Series LED Version Installation and Operation Manual Appendix A: Compatible Receivers The dialers that are built into select models of the FA-300 Series Fire Alarm Control Panels are compatible with the following Digital Alarm Communicator Receivers (DACR): DACR Receiver Model Protocols SurGard MLR2 Multi-Line Receiver (ULC, ULI approved) SIA-DCS and Ademco Contact ID...

  • Page 76: Appendix B: Reporting

    Appendix B: Reporting Appendix B: Reporting Ademco Contact-ID FA-300 Event Codes Event Description Event Family Qualifier Code Group # Contact # Phone Line #1 trouble detected Trouble New event 1 351 Phone Line #2 trouble detected Trouble New event 1 352 Phone Line #1 trouble restored Trouble Restore...

  • Page 77: Security Industries Association Sia-Dcs

    FA-300 Series LED Version Installation and Operation Manual Security Industries Association SIA-DCS SIA protocol does not define indicating zone troubles, but lists it as Untyped Zone Trouble/Restore. FA-300 Event Codes SIA Event Event Description Event Family Qualifier Parameter Code Phone Line #1 trouble detected Trouble New event Phone Line #2 trouble detected...

  • Page 78: Appendix C: Specifications

    System Model: FA-300 Series LED Version Fire Alarm Control Panel System Type: Local, Auxiliary (using PR-300), Remote Protected Premises Station (using PR-300 or FA-301-12LDR, FA-301-12LDW, or FA-301-8LDW) Central Station Protected Premises (using FA-301-12LDR, FA-301-12LDW, or FA-301-8LDW) Type of Service: A, M, WF, SS Type of Signalling: Non-Coded Applicable Standards: NFPA 70 and 72, UL-864 Rev.

  • Page 79: Appendix D: Power Supply And Battery Calculations (Selection Guide)

    * Assume three Initiating Circuits are in alarm. ' Use 0.084 for five minutes of alarm as a multiplier figure. Using the Mircom MPD-65P 2-wire photoelectric smoke detector. See Appendix A for other compatible smoke detectors. Total Current Requirement: ALARM (B)______ Amps. (Value obtained from column B) Battery Capacity Requirement: ([STANDBY (A) ______ ] X [(24 or 60 Hours) ___ ]) + ([ALARM (B) ______ ] X [Alarm in Hr.] _____) = (C) ______AH...

  • Page 80: Warranty & Warning Information

    Warranty & Warning Information Warranty & Warning Information Warning Please Read Carefully Note to End Users: This equipment is subject to terms and conditions of sale as follows: Note to Installers This warning contains vital information. As the only individual in contact with system users, it is your responsibility to bring each item in this warning to the attention of the users of this system.
  • Page 81 Mircom shall not be liable for any delays, breakdowns, interruptions, loss, destruction, alteration or other problems in the use of a product arising our of, or caused by, the software.

  • Page 82: Limited Warranty

    (90) days, whichever is longer. The original owner must promptly notify Mircom Technologies Ltd. in writing that there is defect in material or workmanship, such written notice to be received in all events prior to expiration of the warranty period.

  • Page 83: Out Of Warranty Repairs

    Products which Mircom Technologies Ltd. determines to be repairable will be repaired and returned. A set fee which Mircom Technologies Ltd. has predetermined and which may be revised from time to time, will be charged for each unit repaired.
  • Page 84 CANADA - Main Office U.S.A TECHNICAL SUPPORT © Mircom 2012 25 Interchange Way 4575 Witmer Industrial Estates North America Printed in Canada Vaughan, ON L4K 5W3 Niagara Falls, NY 14305 Tel: (888) Mircom5 Subject to change without prior notice Tel: (888) 660-4655...
