5.0 Cable and Jumper Connections for
Main Board, Core Board and Adder
Modules
5.1

Main Pre-Action/Deluge and Agent Release Control Board

•
For front panel programming use CFG-300
configuration tool not UL-864 or ULC-S527 listed.
Please refer to Document LT-922 for details
Main Board
JW4 - Normally closed
JW5 - Normally open
JW6 - Normally open
+
RS-485 for
annunciators
S
NO
Auxillary
C
Relay
NC
NO
Alarm
C
Relay
NC
NO
Supervisory
C
Relay
NC
NO
Trouble
C
Relay
JW2 - ON - when
NC
RM-306 not
connected
JW1 - ON
Figure 7
18
JW4 - Normally closed
U15
AC ON
X
COMMON ALARM
COMMON SUPV
M
COMMON TROUBLE
BATTERY TROUBLE
REMOTE TROUBLE
?
GROUND FAULT
CPU FAIL
ABORT
RELEASE
SYSTEM
RESET
SIGNAL
SILENCE
AUXILIARY
DISCONNECT
LAMP
TEST
ALM/SUP/TBL/
BLDG AUDIBLE SIL
PRE
RELEASE
P3 P4
Unused Connect to RM-306
Relay module
Main Control Board cable connector and jumper settings
JW5 - Normally open
Core Board
IDC 1
IDC 2
IDC 3
IDC 4
IDC 5
IDC 6
NAC 1
NAC 2
RAC 3
RAC 4
P2 P1
Power supply and control
interface, including AC
power and battery
supplies
Connect UIMA interface module
for upgrading firmware
P7
+
DET 1
+
DET 2
+
DET 3
+
DET 4
+
DET 5
+
DET 6
+
SIG 1
+
SIG 2
+
SIG 3
+
SIG 4
+
Auxiliary
power supply
+ Four wire
smoke
detector
power
supply
TRB TRL
COM+
Connect Unfiltered
to RTI-1
24V
supply
