11.14 Mode 14: Pre-action/Deluge, Single Hazard, Not Cross-zoned,
Combined Release
!
Attention: This mode of operation is neither FM nor UL approved.
Out1 Signal Steady
Out2 Signal Escalating
Out3 Rel. Releasing
Out4 Rel. Releasing
RLS TMR 1 Started
RLS Tmr 1 Interrupted
RLS Tmr 1 Cancelled
11.14.1 Zone Configuration
• Detection Zone -1: Alarm (Hazard Area 1, not cross-zoned)
• Detection Zone -2: Alarm (Hazard Area 1, not cross-zoned)
• Detection Zone -3: Alarm (Hazard Area 1, not cross-zoned)
• Detection Zone -4: Alarm (Hazard Area 1, not cross-zoned)
• Detection Zone -5: Supervisory
• Detection Zone -6: Water-flow
• NAC -1: Signal, steady on any alarm
• NAC -2: Escalating Signal, indicates Hazard Area 1 status, Supervisory Optional
• RAC -3: Releasing Circuit (Hazard Area 1)
• RAC -4: Releasing Circuit (Hazard Area 1)
11.14.2 Hazard Configuration
• Default Release Timer Value:
• Default Manual Release Delay:
• Default Abort Delay Type:
• Default Soak Timer Value:
11.14.3 NAC Configuration
• Default Escalating NAC code of Hazard Area State:
• Hazard Idle: Off
• Hazard Alert: Temporal (see Table 9 and Table 10)
• Hazard Alarm: Temporal (see Table 9 and Table 10)
• Hazard Release: Steady
• Default NAC code of Supervisory is 20 BPM.
Detection Zones
Z1 Z2 Z3 Z4
Alm Alm Alm Alm
X X X X
X X X X
0 seconds
0 seconds (not used)
Standard UL (not used)
0 seconds (continuous)
Phantom Zone
Z5 Z6 Zp1
Supv WF Z1+Z2+Z3
X
(X) X X
Release Timer
RT1 Exp
X
X
