Hardware Installation and Reference Guid
Table 1-2 Side View
No. Button and Port
Anti-theft lock hole
1
2 Reset button
3 Console port
10/100/1000 BASE-T Ethernet
4
port
5 DC power plug
1.2

Package Contents

Table 1-3 Package Contents
Item
RG-AP810-I Access Point
Mounting Bracket
Wall Anchor
Phillips Pan Head Screws M4 x 20
Warranty Card
Quick Start Guide
1.3

Technical Specifications

1.3.1

Size and Weight

Table 1-4 Size and Weight
Item
Main Unit
Dimensions
(W x D x H)
Weight
Parameter
220 mm × 220 mm × 49 mm (8.66 in. x 8.66 in. x 1.93 in.)
Main Unit: 0.6 kg (1.32 lbs.)
Bracket: 0.2 kg (0.44 lbs.)
Description
Connect to the anti-theft lock.
Reboot the device or restore the device to
factory settings.
Connect to the device that is managed with
the serial cable.
The uplink adaptive Ethernet port for service
data transmission.
IEEE 802.3af-compliant.
Connect to the DC power adapter to supply
power to the AP.
Quantity
1
1
2
4
1
1
3
Product Overview
