Hardware Installation and Reference Guid
Figure 3-2 Attaching the Mounting Bracket to the Ceiling
(2) Align the square feet on the rear of the AP with the mounting holes on the bracket.
Figure 3-3 Aligning the Square Feet with the Mounting Holes
Caution
Install the Ethernet cables before mounting the AP on the bracket.
(3) Slide the AP onto the bracket in the opposite direction of the arrow on the mounting
bracket until it clicks into place.
Figure 3-4 Mounting the AP on the Bracket
18
Installing the Access Point
