Hardware Installation and Reference Guide

Package Contents

1.2
Package contents
Table 1-1
Name
Master AP
Mounting bracket
Rubber pad
Network product warranty and hazardous
substance list
M4*8 Phillips countersunk screw GB819-85
Yellow/green ground cable
Management software
AC power cable
Spring clip

Appearance

1.3
The front panel of RG-AM5528-SF provides 24 1G/2.5G downlink SFP ports, 24 PoE power
feeding ports, 4 10G SFP Plus ports, 1 management Ethernet port (MGMT), and 1 Console port.
The rear panel provides AC power input port. The product appearance is as follows:
Side Panel
Figure 1-1

Front Panel

1.3.1
Front Panel
Figure 1-2
Quantity
1
2
4
1
6
1
1
1
1
2
Product Overview
