Hardware Installation and Reference Guid
Antenna Type
Antenna Gain
Max. Transmit
Power
Transmit
Power
Adjustment
Modulation
Receive
Sensitivity
1.3.3

Ports

Table 1-6 Ports
Item
Bluetooth
Built-in omnidirectional antenna
2.4 GHz: 2 dBi
5 GHz: 2 dBi
20 dBm (country-specific restrictions apply)
Configurable in increments of 1 dBm
OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-
QAM@48/54Mbps
DSSS: DBPSK@1Mbps, DQPSK@2Mbps, and CCK@5.5/11Mbps
MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM and 1024QAM
OFDMA
11b: -96dBm(1Mbps), -93dBm(5Mbps), -89dBm(11Mbps)
11a/g: -91dBm(6Mbps), -85dBm(24Mbps), -80dBm(36Mbps), -
74dBm(54Mbps)
11n: -90dBm@MCS0, -70dBm@MCS7, -89dBm@MCS8, -
68dBm@MCS15
11ac: HT20: -88dBm(MCS0), -63dBm(MCS9)
11ac: HT40: -85dBm(MCS0), -60dBm(MCS9)
11ac: HT80: -82dBm(MCS0), -57dBm(MCS9)
11ax: HE80: -82dBm(MCS0), -57dBm(MCS9),-52dBm(MCS11)
Description
Bluetooth 5.1
5
Product Overview
