Ruijie RG-AP810-I Access Point
Hardware Installation and Reference Guide
Document Version: V1.5
Date: June 6, 2024
Copyright © 2024 Ruijie Networks

Advertisement

loading
Need help?

Need help?

Do you have a question about the RG-AP810-I and is the answer not in the manual?

Questions and answers

Related Manuals for Ruijie RG-AP810-I

Summary of Contents for Ruijie RG-AP810-I

  • Page 1 Ruijie RG-AP810-I Access Point Hardware Installation and Reference Guide Document Version: V1.5 Date: June 6, 2024 Copyright © 2024 Ruijie Networks...
  • Page 2 The content of this document is subject to constant change due to product version upgrades or other reasons. Thus, Ruijie Networks reserves the right to modify the content of the document without prior notice or prompt. This manual serves solely as a user guide. While Ruijie Networks endeavors to ensure the accuracy and reliability of the content when compiling this manual, it does not guarantee that the content of the manual is free of errors or omissions.

  • Page 3: Preface

    This document is intended for:  Network engineers  Technical support and servicing engineers  Network administrators Technical Support  Ruijie Networks Website: https://www.ruijienetworks.com/  Technical Support Website: https://ruijienetworks.com/support  Case Portal: https://caseportal.ruijienetworks.com  Community: https://community.ruijienetworks.com  Technical Support Email: service_rj@ruijienetworks.com ...
  • Page 4 Note This manual provides the device installation steps, hardware troubleshooting, module technical specifications, and specifications and usage guidelines for cables and connectors. It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it is assumed that the users are already familiar with the related terms and concepts.

  • Page 5: Table Of Contents

    Contents Preface ..............................I 1 Product Overview ..........................1 1.1 Appearance ..........................1 1.2 Package Contents........................3 1.3 Technical Specifications ......................3 1.3.1 Dimensions and Weight ....................3 1.3.2 System Specifications ....................4 1.3.3 Wi-Fi Radio ........................4 1.3.4 Bluetooth Radio ......................9 1.3.5 Ports Specifications .......................
  • Page 6 2.2.3 Space Requirement ..................... 13 2.2.4 Temperature/Humidity Requirements ................13 2.2.5 Cleanliness Requirements ................... 14 2.2.6 Anti-interference Requirements ................... 15 2.2.7 Installation Site Requirements ..................15 2.3 Tools ............................15 3 Installing the Access Point ......................16 3.1 Installation Flowchart ....................... 16 3.2 Before You Begin ........................
  • Page 7 4.1 Configuring the Environment ....................26 4.2 Powering up the AP ......................... 26 4.2.1 Checking Environment before Power-on ..............26 4.2.2 Checking Environment after Power-on ................ 26 5 Monitoring and Maintenance ......................27 5.1 Monitoring ..........................27 5.1.1 LED ..........................27 5.1.2 CLI Commands ......................

  • Page 8: Product Overview

    The RG-AP810-I AP is a dual-band dual-radio access point compliant with the IEEE 802.11ax standard. The RG-AP810-I AP provides a combined data rate of 1.775 Gbps, with up to 574 Mbps in the 2.4 GHz band and 1.201 Gbps in the 5 GHz band, available for flexible deployments in the field of education, government, finance and business.
  • Page 9 Hardware Installation and Reference Guide Product Overview Figure 1-2 Front Panel Table 1-1 Front Panel Item Description Indicate the operation status of device. Figure 1-3 Side View Table 1-2 Side View Button and Port Description...

  • Page 10: Package Contents

    Note The nameplate is at the bottom of the access point. Package Contents Table 1-3 Package Contents Item Quantity RG-AP810-I Access Point Mounting Bracket Wall Anchor Phillips Pan Head Screws M4 x 20 Warranty Card Quick Start Guide Technical Specifications 1.3.1...

  • Page 11: System Specifications

    Hardware Installation and Reference Guide Product Overview Dimensions and RG-AP810-I Weight Lock option Kensington lock and securing latch Mounting bracket dimensions 120 mm×120 mm×8 mm (4.72 in. x 4.72 in. x 0.31 in.) (W x D x H) Mounting hole 53mm×53mm (2.09 in.
  • Page 12 Hardware Installation and Reference Guide Product Overview Wi-Fi Radio RG-AP810-I Four spatial streams Radio 1 – 2.4 GHz: 2x2 MIMO, two spatial streams Radio 2 – 5 GHz: 2x2 MIMO, two spatial streams Channels: Radio 1 – 2.4 GHz: 20 MHz and 40 MHz Radio 2 –...
  • Page 13 Hardware Installation and Reference Guide Product Overview Wi-Fi Radio RG-AP810-I Transmit beam-forming (TxBF) Four spatial streams Radio 1 – 2.4 GHz: 2x2 uplink/downlink MU-MIMO , two spatial streams Radio 2 – 5 GHz: 2x2 uplink/downlink MU-MIMO, two spatial streams Channels: Radio 1 –...
  • Page 14 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM 802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM The following table lists the radio frequency performance of Wi-Fi including different frequency bands, protocols, and date rates. It is country-specific, and Ruijie Networks reserves the right of interpretation. Radio Frequency RG-AP810-I...
  • Page 15 Hardware Installation and Reference Guide Product Overview Radio Frequency RG-AP810-I Performance Maximum Receive Frequency Band and Maximum Transmit Power Data Rate Sensitivity per Receive Protocol per Transmit Chain Chain –89 dBm 6 Mbps 23 dBm –82 dBm 24 Mbps 22 dBm 5 GHz, 802.11a...

  • Page 16: Bluetooth Radio

    Hardware Installation and Reference Guide Product Overview 1.3.4 Bluetooth Radio Table 1-7 Bluetooth Radio Bluetooth Radio RG-AP810-I Bluetooth Bluetooth 5.1 Antenna type One onboard omnidirectional antenna Maximum antenna gain 2.4 dBi, with a downtilt angle of roughly 30 degrees 17 dBm (GFSK) Maximum transmit power 14 dBm (π/4-DQPSK, 8-DPSK)

  • Page 17: Power Supply And Consumption

    Product Overview 1.3.6 Power Supply and Consumption Table 1-9 Power Supply and Consumption Power Supply RG-AP810-I Consumption Input power The AP supports the following two power supply modes: supply 48 V DC/0.3 A power input over DC connector: The DC connector accepts 2.1 mm/5.5 mm center-positive circular plug.

  • Page 18: Regulatory Compliance

    Regulatory Compliance Table 1-11 Regulatory Compliance Regulatory compliance RG-AP810-I EN 55032, EN 55035, EN 61000-3-3, EN IEC 61000-3-2, EN 301 489-1, EN 301 Regulatory compliance 489-3, EN 301 489-17, EN 300 328, EN 301 893, EN 300 440, FCC Part 15, EN...

  • Page 19: Preparing For Installation

    Hardware Installation and Reference Guide Preparing for Installation Preparing for Installation Safety Precautions Note  To avoid personal injury and device damage, carefully read the safety precautions before you install the device.  The following safety precautions may not cover all possible dangers. 2.1.1 General Safety Precautions ...

  • Page 20: Storage Safety

    Hardware Installation and Reference Guide Preparing for Installation  Learn about the position of the indoor emergency power switch before installation. Cut off the power switch in case of accidents.  Check the device carefully before shutting down the power supply. ...

  • Page 21: Cleanliness Requirements

    Hardware Installation and Reference Guide Preparing for Installation Note The ambient temperature and humidity of the device are measured at the point that is 1.5 m (59.06 in.) above the floor and 0.4 m (15.75 in.) before the device when there is no protective plate in front or at the back of the device.

  • Page 22: Anti-Interference Requirements

    Hardware Installation and Reference Guide Preparing for Installation Note Average refers to the average value of harmful gases measured in one week. Maximum refers to the upper limit of harmful gases measured in one week, and the maximum value lasts up to 30 minutes every day. 2.2.6 Anti-interference Requirements ...

  • Page 23: Installing The Access Point

    Hardware Installation and Reference Guide Appendix Installing the Access Point The RG-AP810-I AP must be fixed and installed indoors. Caution Before installing the device, make sure you have carefully read the requirements described in Chapter 2. Installation Flowchart Start Preparation before installation...

  • Page 24: Precautions

    Hardware Installation and Reference Guide Appendix in case of accidents.  For ceiling-mounted or wall-mounted AP, the mounting bracket size, mounting hole pattern and diameter should meet the requirements in Table 1-4. Figure 3-1 Mounting Bracket Precautions To avoid damage to the AP, observe the following safety precautions: ...

  • Page 25: Installing The Access Point

    Hardware Installation and Reference Guide Appendix  Do not wash the device with liquid.  Do not open the enclosure when the device is working.  Fasten the device tightly. Installing the Access Point Note  You are advised to install the device where you can get the optimal coverage. ...

  • Page 26: Wall Mounting

    Hardware Installation and Reference Guide Appendix (3) Slide the AP onto the bracket in the opposite direction of the arrow on the mounting bracket until it clicks into place. Figure 3-4 Mounting the AP on the Bracket Caution  The AP can be installed in any of four directions on the mounting bracket depending on how you route the Ethernet cable.

  • Page 27: Securing The Access Point

    Figure 3-7 Mounting the AP on the Bracket Caution  When mounting the AP on the wall, keep the Ruijie logo pointed upwards.  The square feet should fit easily into the mounting slots. Do not forcibly push the AP into the slots.

  • Page 28: Removing The Access Point

    Hardware Installation and Reference Guide Appendix (2) Align the square feet on the rear of the AP over the mounting holes on the bracket, slide the AP in the opposite direction of the arrows on the mounting bracket until it clicks into place. Figure 3-9 Mounting the AP on the Bracket Caution Install the Ethernet cables before mounting the AP on the bracket.

  • Page 29: Connecting Cables

    Hardware Installation and Reference Guide Appendix Figure 3-10 Removing the Ceiling-mounted AP (2) If the AP is installed on the wall, hold the AP in your hands and push it upward and away from the bracket in the LAN port direction. Figure 3-11 Removing the Wall-mounted AP Connecting Cables Connect UTP/STP to the LAN/PoE port on the AP.
  • Page 30 Hardware Installation and Reference Guide Appendix Table 3-1 1000BASE-T Twisted Pair Connections 10BASE-T uses 100-ohm Category-3/4/5 UTP or STP, and 100BASE-TX uses 100-ohm Category-5 UTP or STP for connections. Both support a maximum length of 100 meters (328.08 ft.). Table 7-2 shows 100BASE- TX/10BASE-T pin assignments.
  • Page 31 Hardware Installation and Reference Guide Appendix Table 3-3 100BASE-TX/10BASE-T Twisted Pair Connections...

  • Page 32: Bundling Cables

    Hardware Installation and Reference Guide Appendix for supported wiring of twisted pairs. Caution By default, baud rate is set to 9600, data bit 8, parity none, stop bits 1 and flow control none on the Console port of the AP. The console port is used only when you want to configure the AP manually. Bundling Cables 3.8.1 Precautions...

  • Page 33: Verifying Operating Status

    Hardware Installation and Reference Guide Appendix Verifying Operating Status Configuring the Environment Use a power adapter or PoE to power the AP. Setting up the Environment  Verify that the AP is properly connected to the power source.  Connect the AP to an AC through a twisted pair cable. ...

  • Page 34: Monitoring And Maintenance

    Hardware Installation and Reference Guide Appendix Monitoring and Maintenance Monitoring 5.1.1 You can observe the LED to monitor the AP in operation. 5.1.2 CLI Commands You can run related commands on the command line interface (CLI) of the device to remotely monitor the configurations and status of the AP.

  • Page 35: Troubleshooting

    Hardware Installation and Reference Guide Appendix Troubleshooting Troubleshooting Flowchart Troubleshooting 6.2.1 Ethernet Port Is Not Working After the Ethernet Cable Is Plugged In Verify that the device at the other end of the Ethernet cable is working properly. And then verify that the Ethernet cable is capable of providing the required data rate and is properly connected.

  • Page 36: Led Keeps Steady Red

    Hardware Installation and Reference Guide Appendix 6.2.3 LED Keeps Steady Red The LED keeps steady red for a long time, indicating that the Ethernet port is not connected. Verify the Ethernet connection. 6.2.4 LED Keeps Steady Green The device performs initialization after power-on. During this period, the LED keeps steady green and does not turn normal blue until the initialization is completed.

  • Page 37: Appendix

    Hardware Installation and Reference Guide Appendix Appendix Connectors and Media  1000BASE-T/100BASE-TX/10BASE-T port The 1000BASE-T/100BASE-TX/10BASE-T port is a 10/100/1000 Mbps auto-sensing port that supports auto MDI/MDIX Crossover. Compliant with IEEE 802.3ab, the 1000BASE-T port requires 100-ohm Category 5/5e UTP or STP with a maximum distance of 100 meters (328.08 ft.).
  • Page 38 Hardware Installation and Reference Guide Appendix 4, 5, 7, 8 Not Used Not Used Table 7-3 shows wiring of straight-through and crossover cables for 100BASE-TX/10BASE-T. Table 7-3 100BASE-TX/10BASE-T Twisted Pair Connections...

  • Page 39: Cabling Recommendations

    Hardware Installation and Reference Guide Appendix Cabling Recommendations During installation, route cable bundles upward or downward along the sides of the rack depending on the actual situation in the equipment room. All cable connectors should be placed at the bottom of the cabinet rather than be exposed outside of the cabinet.
  • Page 40 Hardware Installation and Reference Guide Appendix cables. ○ After bundling up cables with cable ties, cut off the remaining part. The cut should be smooth and trim, without sharp corners, as shown in Figure 7-5. Figure 7-2 Cutting off Excess Cable Tie ○...
  • Page 41 Hardware Installation and Reference Guide Appendix Figure 7-4 Fastening Cable Lugs Note 1. Flat washer 3. Spring washer 2. Nut 4. Flat washer ○ Hard power cords should be fastened in the terminal connection area to prevent stress on terminal connection and cable.

  • Page 42: Power Supply

    Hardware Installation and Reference Guide Appendix Power Supply  DC power adapter: Input voltage: 48 V Rated current: 0.3 A  Technical Specifications of the DC Power Connector Inner Diameter Outer Diameter Depth Polarity Inner pole: positive 2.1 mm (0.08 in.) 5.5 mm (0.22 in.) 10 mm (0.37 in.) Outer pole: negative...
